Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Thermal insulation of traditional aluminum foil woven fabric
Specifications
Warranty :
2 years
After-sale Service :
Online technical support, Onsite Installation
Project Solution Capability :
Others
Application :
Warehouse, Thermal Insulation
Design Style :
Traditional
Place of Origin :
Shanghai, China
Brand Name :
FANRYN
Model Number :
woven foil insulation
Material :
aluminium foil/pe/pe woven cloth
Width :
500mm-2000mm
Length :
50m-2500m
weight :
100gsm-200gsm
Color :
Silver
Thermal conductivity :
0.032W/mk
Reflectivity :
96-97%
Package :
PE Bag
Supply Ability :
20 Twenty-Foot Container per Day
MOQ :
2000.0 Square Meters
Description

thermal insulation aluminum foil woven fabric

Item aluminum foil woven fabric Size 130μm
NO. Item Units Test Method Test Results
1 Thickness μm Vertical optical meter 130
2 Grammage g/m2 Electronic analytical balance 125
4 Tensile Strength Machine Direction (kN/M) Tensile tester min 9.5
5 Lateral Direction min 6.0
6 Edge Tear Resistance Machine Direction (N) Tensile tester min 65
Lateral Direction min 65
7 Water Vapor Transmission Rate (Ng/Ns) Tensile tester max 2
8 Emmitance Reflective
9 Vapor barrier High
10 Water Barrier High
11 Emmittance of Reflective Face max 0.05

Thermal insulation of traditional aluminum foil woven fabric

Thermal insulation of traditional aluminum foil woven fabric

Thermal insulation of traditional aluminum foil woven fabric

Advantages

1.Reflects at least 96%radiant heat

2.Non-toxic/Non-allergic

3.Durable and light weight

4.Does not being compressed,collapsed or not easy being damaged

5.Easy to be cut and install

6.Stop the growth of mold and mildrew

Packaging & Shipping

Each roll will be packed by kraft paper and PE fil, then put into pallets.

Our Services

One year warranty for all products

Necessary technical support

Delivery quality products with excellent service on time

Supply one stop solution on insulation and ventilation products

Supply high level QC service

Company Information

BEIJING FANRYN TECHNOLOGY LTD is a global and multiple company, specializes in developing, manufacturing, and sales of HVAC products. Our technical team enjoys 20 years' experience in developing and producing of insulation material ventilation products and tape products. Our head office is located in Beijing China. Currently, we have wholly-owned overseas subsidiaries and branches in 4 countries with a view to realize localization, which also represents an essential progress in our globalization target.

FAQ

Q: What are the benefits of your facing?

A: Our facing is light, soft, dust free, fire resistant, easy to install. Also the material is eco-friendly, non-toxic and have better heat insulation.

Q: Can I get some samples for testing before placing order?

A: Yes, we can provide you some free samples for your reference if you would like to bear the express cost.

Q: Can you make other sizes and packages for this product?

A: Yes, we can make other sizes as your requirement, normally our quotation will contain the common package. If you need your own packages, you'd better advise your requirement ahead of time for an accurate quote.
