High Speed Edgebanding Machine FV691

FEATURES

• The gluing unit features quick melt and an application device that guarantees perfect glue quality on different edge materials.

• Temperature adjustable by control. When the edgebander is running without workpiece, the system automatically stops heating up the glue.

• The trimmed edge is always finished with a clean cut thanks to the precision linear guide and the high speed motors.

• Quick changeover between different edges can be easily realized by clicking on the touchscreen.

• 4 motors that travel in a reciprocating motion to clean and buff the workpiece.

TECHNICAL DATA

DETAILS PICTURES

Top pre-melter reduces heating time and increase the quality of edgebanding.

Servo Tape Magazine

Four wheel tape magazine automatically changes edge with servo motor.

The process is both accurate and swift.

• One big precision roller and 5 small to make sure the edge is pressed seamlessly to the workpiece.

• The big roller and gluing rollers press simultaneously. The 5 small rollers consist of 1 cylinder shaped and 4 cone shaped rollers. The latter further ensures that the edge is properly pressed to the workpiece.

• All rollers have their independent pressure control valve.



  Double V-belt Top Pressure System


  Spraying Unit

  This device spray-applies a thin coat of release agent to upper and lower edge area of the workpiece and prevent squeezed out glue from adhering to the workpiece.

  Hot Air Edgebanding Technology

  Available Upon Request

  Zero glue line, Minimum heating time required, water-resistant, saving the trouble of cleaning the glue pots

  To be used with edges with PVC, ABS, PP, PMMA or melamine coating.



  Double Glue Reservoirs

  Available Upon Request

  Two glue reservoirs to quickly switch between colors and to achieve invisible joint.



  Flat Scraping


  R Scraping


  Trimming


  Corner Trimming Unit

  With 4 motors, this device works well with various edge thickness and invariably result in perfect round corner.


  Pre-milling Unitl

• Equiped with diamond tools for better cut and longer use

• This device removes the burr or unevenness on the edge of the workpiece, leaving a smooth surface for the edgebanding.

• Profiling unit available upon request.
