High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M
High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M
Specifications
Brand Name :
FAST CNC
Model Number :
LF60M
Certification :
ISO9001
Place of Origin :
Jinan China
MOQ :
1 SET
Price :
USD 27000~37500/Set
Payment Terms :
L/C, T/T
Supply Ability :
300sets/year
Delivery Time :
30days
Packaging Details :
Plywood box
Condition :
New
Pipe diameter range (Diameter of circumscribed circle) :
Φ10~φ210mm
Max. Pipe length :
6000mm
W-axis rotation angle :
n*360
W axis maximum speed :
120RPM
X/Y axispositioning accuracy :
±0.05mm
X axis maximum moving speed :
40m/min
X/Y maximum acceleration :
1.0G
Chuck :
Pneumatic
Guide rail width :
35MM
Description

3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

ADVANTAGE

1. Professional pipe cutting machine

2. The newest pneumatic chuck

3. Easy to Operate

TECHNICAL DATA

MODEL LF60M

Pipe diameter range

(Diameter of circumscribed circle)

 Φ10~φ210mm
Max. Pipe length 6000mm
X-axis travel 330mm
Y-axis travel 6500mm
Z-axis travel 350mm
W-axis rotation angle n*360
W axis maximum speed 120RPM
X/Y axis positioning accuracy ±0.05mm
X/Y axis repeat positioning accuracy ±0.03mm
X axis maximum moving speed 40m/min
Y axis maximum moving speed 30m/min
X/Y maximum acceleration 1.0G
Chuck Pneumatic
Maximum load of chuck 200kg 35kg/m
Guide rail width 35MM
Lubrication type Automatic oiling
Lubrication type Automatic oiling
Power available 1000-3000W
Dimension 11900*1880*2260mm
Total Weight 4500kg

DETAIL IMAGES

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

SAMPLES

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

WHY CHOOSE US

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

COMPANY PROFILE

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

WORKSHOP

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

CUSTOMER VISIT

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

FAQ

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

CERTIFICATE

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M

PACKING AND SHIPPING

High Quality 3000W CNC Fiber Laser Tube Cutting Machine ISO CNC Laser Pipe Cutter Model LF60M
