12 Volt High Force Electric Actuator 1000kg Load Lift Motorhomes / Toy Hauler
12 Volt High Force Electric Actuator 1000kg Load Lift Motorhomes / Toy Hauler
12 Volt High Force Electric Actuator 1000kg Load Lift Motorhomes / Toy Hauler
12 Volt High Force Electric Actuator 1000kg Load Lift Motorhomes / Toy Hauler
12 Volt High Force Electric Actuator 1000kg Load Lift Motorhomes / Toy Hauler
12 Volt High Force Electric Actuator 1000kg Load Lift Motorhomes / Toy Hauler
Specifications
Brand Name :
OEM
Model Number :
LINEAR ACTUATOR
Certification :
CE
Place of Origin :
MADE IN CHINA
MOQ :
4pcs high force linear actuators
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000pcs electric linear actuator per month
Delivery Time :
8-10 work days
Packaging Details :
Carton box
Item name :
High force linear actuator
Duty cycle :
25%
Limit switch :
Integrated
Motor :
Brushed DC Motor
Feature :
Waterproof
Max. load :
12000n
CE :
Certified
Material :
Stainless Steel rod
Description

High force Linear Actuators 250mm/300mm stroke 1000KG load lift motorhomes/Toy hauler, 12volt

Specification of electric actuator:

Type Electric linear actuator
Motor type Brush DC motor
Cable Bare wire 0.4m
Voltage 24VDC
Screw type ACME
Noise level ≤75dB
Limit switches Integrated non-adjustable
Stroke tolerance ±3mm
Duty cycle 25%
Production class IP65
Feedback Hall sensor/pot
Operating and storage temperature -40℃~+65℃
Manufacturing quality standards ISO9001:2015

Features of industrial linear actuator:

* Built-in end-stop

* Stainless Steel rod

* IP65 Protection

* CE Certified

* Limit Switch Integrated

* Max. Load 12000N

* Input Voltage 12V, 24VDC

* Signal Feedback Potentiometer or Hall Sensor

Load & Speed of the high force linear actuator

High Force Linear Actuator Load±10％(N) Speed±2(mm/S)
Load 12,000 10,000 7,000 3,000
Speed 6.5 13 17 35

Picture of the waterproof linear actuator, outdoor use

12 Volt High Force Electric Actuator 1000kg Load Lift Motorhomes / Toy Hauler

Mini linear actuator

High performance 12 / 24/36/48V DC motor

• Protection class: IP65

• Stroke: 50 to 600 mm

• Retracted length: S+105mm

• Load capacity: up to 1200 N

• Maximum load speed: 4 to 60 mm/s

• Option ball screw

• Stainless steel version (304 inner tubes)

• CE certification

• Low-temperature version from -40 ° C to + 65 ° C

• Duty cycle 25%

• Other options on request (fixing, stroke, connection, potentiometer, ...)

12 Volt High Force Electric Actuator 1000kg Load Lift Motorhomes / Toy Hauler

How do I select electrical actuators?

It really depends on your needs.

* Stroke length (travel length)

* Installation length

* Mounting requirements

* Feedback(Hall sensor/Magnetic reed switch)

* Motor voltage

* Dynamic load

* Static load

* Speed

* Precision

* Others

Application of linear actuators:

Electric Linear Actuator for Tractor

Welcome to visit our factory in China.

12 Volt High Force Electric Actuator 1000kg Load Lift Motorhomes / Toy Hauler

Are you interested in knowing more information about linear actuators, motors?

Please contact us!

Lisa Hao

WhatsApp/Cell: +86 18762658863

www.fastlinearactuator.com

www.linearactuatorsshop.com
