Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
Specifications
Brand Name :
SNYNXN
Model Number :
FL 3
Certification :
SGS CE ISO GMP
Place of Origin :
JIANGSU CHINA
MOQ :
1 SET
Price :
NEGOTIABLE
Payment Terms :
T/T, L/C
Supply Ability :
100 SETS/ YEAR
Delivery Time :
20 DAYS
Packaging Details :
Film wrapping, wooden case.
Type :
Fluid Bed Drying and Granulating Equipment
Application :
Medicine Processing, Chemicals Processing, Plastics Processing, Food Processing Line
Evaporation Capacity :
23 (kg/h)
Output capacity :
1.5-4 kg
Heat Method :
Electric Heating
Processing :
Spray Drying and Granulation
Case Body Shape :
Square-shape
Construction Material :
Stainless Steel 304 / SUS316L
After sales Warranty :
supply Video, online technical support, Spare parts
Warranty :
1 Year, 2 years of core components
Description

Description of FL Series Mini Fluidized Bed Drying Granulator Machine

Pharmaceutical Lab Use Mini Fluidized Bed Drying Granulator Machine Fluid Bed Dryer

The fluidized granulator is a new craft set combining the fluidized bed technology and spraying technology to make granules in medical industry, foodstuff, chemical industry and so on.

Features

(1) It has four functions: Mixing, drying, granulating. it can make powder material into granules by one step directly, dry the material, and quickly fluidizing granulate.

(2) Under airtight negative pressure condition, clearance, no dead angle.

(3) Making use of the fluidized material as wet sticky thing to make granules can save much alcohol and bring down the cost, and can produce small, no sugar or low sugar medical particle. (4) The final products can be easy fusion and decomposed.


Principle of work:

The powder granule in the container (fluization) appear in the state of fluidization. It is preheated and mixed with clean and heated air. At the same time the solution of adhesive solvent is fogged and sprayed into the container. It makes some particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulation is evaporated and the adhesive is solidification. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.

Applications
Drug granulation and coating.
Granulation: tablet granule, granule for granule, capsule granule. Coating: pellet, pill protective layer, color slow release, film, enteric coating. Food granulation and coating
Fried sugar, coffee, cocoa powder, cream powder juice, amino acid, seasoning, puffed food. Granulation of pesticides, pigments and dyes. Powder, granule, block material drying.


Technical Data

Capacity (Kg /batch) 5 15 30 60 120 200 300 500 800-1000
Scope of application for liquid(g/cm3) <1.3


By client
Material yield rate (%) ≥99
Qualified rate of end products (%) ≥85
Container volume (L) 22 45 100 220 420 670 1000 1500
Diameter r(mm) 500 550 700 1000 1200 1400 1600 1800
Power of fan (Kw) 3 5.5 7.5 11 18.5 22 30 45
Power of supply liquid motor (Kw) 0.37
Pressure of steam (Mpa) 0.4-0.6
Consumption of steam (Kg/h) 18 35 60 120 140 180 310 400
Pressure of compressed air (Mpa) 0.4-0.6
Working temperature (℃) Normal temperature -120℃ could adjust
Overall dimension of machine (L×W×H) refer to installation drawing or customer’s room


Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine

Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine


OUR FACTORY:

Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
Pharmaceutical Lab Use Mini Fluid Bed Spray Granulator Drying Machine
FAQ

Q1:Are You A Factory or A Trading Company?
A: Professional Factory with 15 year history of machine manufacture. We Provided Perfect OEM and After-sale Service.
Q2:Where is Your Factory? How Can I Visit Your Factory?
A:Our Factory is Located in Jiangyin city, Jiangsu Province. We Are Warmly Welcom You Visit Our Factory if You Have a Travel Plan.
Q3:Can You Send Me the Video To Show The Machine Works?
A:Certainly, We Have Made Video of Every Machine
Q4:How Can I Know Your Machine Is Designed For My Product?
A:You Can Send Us Samples of Your Product and We Test It On Machine
Q5:How Can I Pay My Order?
A:Usually We Accept L/C, D/A, D/P, T/T, Western Union, MoneyGram,Cash Paying Methods
Q6:Do you Have a Ce Certificate?
A:For Every Model of Machine, It Has a CE Certificated
Q7:What about install?
A. Our engineers will be sent according to your project.However,the customer will pay the economic air tickets round trip and arrange the accommodation for them.

Before offering you a good price, We need to know the information as below:
What is your material name?
What is the initial moisture percentage before drying?
What is the residual moisture percentage after drying?
What is the heating temperature your material can undertake during dryingprocess?
What is the heating source, steam, electricity, natural gas or others?
Last but important, what is capacity how many kgs/h before drying or after drying?
