The utility model can complete all movements such as lifting, clamping, mixing and falling down automatically. Equipped with an automatic lifting hopper mixer and a number of mixing hopper with different specifications, it can meet the mixing requirements of large quantities and varieties. It is the ideal equipment for pharmaceutical mixing. It is also widely used in the pharmaceutical, chemical, food and other industries.

Principle:

The machine is composed of a frame, a revolving body, a drive system, a lifting system, a braking system and a control system. When the utility model is used, the mixing hopper is pushed into the rotary body, and the mixing hopper is automatically lifted in place and automatically clamped by pressing the confirmation button on the touch screen. The pressure sensor clamp signal, hybrid drive system, a hybrid system is mixed according to the set time and speed; to set the parameters of the rotary body, will automatically stop and brake system vertical, work, and improve the system of work mixed end. The mixing hopper in the rotating body falls in place, stops automatically, and prints the process data. The mixing hopper is pushed out to the next process.

Characteristic:
The rotary body (mixing) into 30 degree angle with the axis of rotation, mixing the material in the hopper with rotary turning, and the bucket wall tangential movement to do, have a strong reversal and high-speed tangential movement, so as to achieve the best mixing results, using PLC automatic control, and set the infrared safety device and anti misoperation device of the discharge valve, to ensure production safety. The material can pass through different process segments in the same container, without frequent feeding and feeding procedures. Effectively control dust and cross contamination, reduce the loss of materials, control the delamination of material, optimize the production process, fully comply with the GMP requirements of pharmaceutical production.
