Specifications
Brand Name :
SNYNXN
Model Number :
SYH
Certification :
CE ISO GMP
Place of Origin :
JIANGSU CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
100 sets / year
Delivery Time :
IN 60 DAYS
Packaging Details :
Standard Export Packing in Wooden case
Product name :
Multi Direction Movable Mixing Machine
Max. Loading Volume :
5 - 1500 L
Materials Type: :
Powder, Pellet, Food and Granules Mixing
Local Service Location :
Serbia, Mexico, Turkey, Viet Nam, Indonesia, Russia, Thailand, Bangladesh, etc.
Core Components :
Motor, Gear, Pressure vessel, Gearbox, Pump, PLC
Warranty of core components :
2 years
Spindle Speed :
10 - 24 r/min
Motor Power :
0.37 - 11 KW
Material :
SUS304, SUS316L, Other, Stainless steel304/316L
After sales Service :
Online Support, Engineers available to service machinery overseas
Description

Name: 3D movement Industrial Mixing Drum Pharmaceutical Mixing Machine.

Features

Because the mixing drum has multi directional motion, it makes raw material inside the drum has many cross-mixing points, therefore the mixing effect is good. Its degree of uniformity may be over 99.9%. Its Max loading efficiency may be 0.9 (The loading efficiency of ordinary mixer is 0.4~0.6). Its mixing time is short and its efficiency is high.
The design of mixing drum is unique. Its inner wall is polished finely. Its advantages are no dead corner, no pollution to raw material, convenient in discharge, easy in clean and so on.

Characteristics:

  1. Designed with three stainless steel interlayer, it helps for accurate control of the temperature of medicine liquid.
  2. Typically designed paddle ensure agitating quickly and mixing uniformly.
  3. Convenience in installation and cleaning. Easy and quick production.

Technical parameters

type SYH-5 SYH-100 SYH-200 SYH-400 SYH-600 SYH-800 SYH-1000 SYH-1500

Material barrel volume (L)		 5 100 200 400 600 800 1000 1500

Max loading volume (L)		 4 80 150 300 450 600 750 1200

Max loading weight (kg)		 3 80 150 200 300 400 500 750

Spindle rotation speed (r/min)		 24 15 12 10 10 10 10 10

Motor power (kw)		 0.37 2.2 3 4 5.5 7.5 11 11

Overall dimensions (mm)		 600×1000
×1000		 1200×1800
×1500		 1300×1600
×1500		 1500×2200 ×1500 1850×2500 ×1650 1900×2400 ×2100 1950×2500 ×2400 2600×2500 ×2350

Weight (kg)		 150 500 750 1200 1500 1650 1800 2500

Industrial Food Mixing Drum Blender Pharmaceutical Machinery SYH Multi Direction Mix

Industrial Food Mixing Drum Blender Pharmaceutical Machinery SYH Multi Direction Mix

Company profile
Division I professional production of various kinds of pharmaceutical machinery and drying equipment, our products sell well in over 20 provinces and cities, and exported to America, Mexico, Spain, Singapore, Russia, belarus, Egypt, South Korea, Malaysia, the Philippines, the united Arab emirates, Thailand, Vietnam, Pakistan, India, Iran, South Africa, Algeria, Syria, Mongolia, Bangladesh and other countries. The company is constantly updating and developing pharmaceutical machinery, chemical equipment, drying equipment, mixing equipment, granulator, coater and sewage treatment equipment and other products. With strict testing means and a complete set of scientific management procedures, and through the ISO9001 international quality system certification, product quality has reached the advanced level at home and abroad, pharmaceutical machinery products in line with "GMP standard". Our company tenet: product quality to win with excellence, sales and service to honesty, the contract to honor the letter.

Industrial Food Mixing Drum Blender Pharmaceutical Machinery SYH Multi Direction MixIndustrial Food Mixing Drum Blender Pharmaceutical Machinery SYH Multi Direction Mix

FAQ

Q: Delivery period:
A: Around 15-60 days, delivery perious will vary as different types of machinery,

Q: Payment of terms:
A: Acceptable payment terms: T/T, L/C, Cash after signing the contract, firstdeposit 30% of total as prepayment, and rest 70% after approvement but before shipment
Q: Quality Warranty:
A: We guarantee all the machines are brand new; We guarantee every set of our machines after shipment have guarantee period 15 months, during warranty period we will provide technician debugging onsite, or free spare parts caused by the malfunction of machines. We guarantee we reply the user's bewilderment within 24 hrs after receive notification.
Q: Package of merchandise:
A: Inner packed with plastic wrapping, external is plywood case. Standerd for epxort packing.
Q: What is service when we place an order with you?
A: First we invite you to visit our factory, and negotiate the tecnnology and choose model of machines, and give feasible advice of each material. Secondly visit our factory to do FAT before shipment, give us your advice and we modify the machine if not meet the user's satisfaction. Lastly, we will dispatch at least 1 experienced and responsible technician to go abroad for commissioning and train the operators. lf no need onsite commissioning, we provide video guidance.
Q: Which information do you require before you could choose model subsequently?
A: We need to know the information as below:
What is your material name?
What is the initial moisture percentage before drying?
What is the residual moisture percentage after drying?
What is the heating temperature your material can undertake during drying process?
What is the heating source, steam, electricity, natural gas or others?
Last but important, what is capacity needed as how many kgs/h before drying or after drying?
