Thermocouple Alloy Wire Alumel 32 AWG Dia 0.203mm Special Grade Extension Wire
Thermocouple Alloy Wire Alumel 32 AWG Dia 0.203mm Special Grade Extension Wire
Specifications
Brand Name :
OHMALLOY
Model Number :
K-BW-1122
Certification :
ISO9001-2008
Place of Origin :
China(Shanghai)
MOQ :
10kg
Price :
negotiable
Payment Terms :
L/C, T/T,
Supply Ability :
100000kg per month
Delivery Time :
7-15 days
Packaging Details :
DIN 125, DIN 160, DIN 200
Material :
Chromel and Alumel
Diameter :
32 AWG
Status :
Bright
Package :
DIN 125, 160
Standard :
ANSI or IEC or DIN
EMF value :
Class 1 accuracy
Description

Thermocouple alloy wire Alumel- 32 AWG - Diam 0.203mm - Special grade

Alumel(KN) is an alloy consisting of approximately 95% nickel, 2% manganese, 2% aluminium and 1% silicon. This magnetic alloy is used for thermocouples and thermocouple extension wire. In thermocouples, alumel is often used together with chromel to form type K thermocouples

(Common Name: KN, NiAl, NiSi3,Thermothal N)

Normal composition%

Nickel 95 Manganese 2
Aluminium 2 Silicon 1

Or

Nickel 97 Manganese 0
Chromium 3 Silicon 0

Properties of Alumel:

CHARACTERISTICS:
Temperature coefficient 0.00032 K−1
Electrical resistivity 0.294 µΩ m
Mechanical properties
Elongation at break <44%
Thermal conductivity 30 W/m/K
Tensile strength 620–780 MPa

Style of supply

Alloys Name Type Dimension
Chromel-W Wire D=0.05mm~12mm
Chromel-R Ribbon W=0.5-10m T=0.05~1.5mm
Chromel-S Strip W=10~150mm T=0.1~3.0
Chromel-B Bar Dia=5-12mm L=50~1500

APPLICATION:

Thermocouple Alloy Wire Alumel 32 AWG Dia 0.203mm Special Grade Extension WireThermocouple Alloy Wire Alumel 32 AWG Dia 0.203mm Special Grade Extension Wire

Product&Package:

Thermocouple Alloy Wire Alumel 32 AWG Dia 0.203mm Special Grade Extension WireThermocouple Alloy Wire Alumel 32 AWG Dia 0.203mm Special Grade Extension Wire

Produce Video:

https://www.youtube.com/watch?v=nsrc2QtPbhU

https://www.youtube.com/watch?v=JsHr_TqPtYU
