AWG 8 3.2mm PFA / PVC Insulated and Sheathed E Type Thermocouple Extension Wire
AWG 8 3.2mm PFA / PVC Insulated and Sheathed E Type Thermocouple Extension Wire
AWG 8 3.2mm PFA / PVC Insulated and Sheathed E Type Thermocouple Extension Wire
AWG 8 3.2mm PFA / PVC Insulated and Sheathed E Type Thermocouple Extension Wire
AWG 8 3.2mm PFA / PVC Insulated and Sheathed E Type Thermocouple Extension Wire
AWG 8 3.2mm PFA / PVC Insulated and Sheathed E Type Thermocouple Extension Wire
Specifications
Brand Name :
OHMALLOY
Model Number :
E-HPF-1115
Certification :
ISO9001-2008
Place of Origin :
China(Shanghai)
MOQ :
100meters
Price :
negotiable
Payment Terms :
L/C, T/T,
Supply Ability :
500000meters/month
Delivery Time :
10-15 days
Packaging Details :
100m/spool, 500m/roll
Conductor :
+Chromel, -Constantan
Conductor dia :
3.2 mm AWG8
Jacket material :
PFA/PVC
Color :
Conforms to ANSI, IEC, JIS
Package :
100m/roll
Standard :
ANSI96.1 or IEC 584-2
Insulation material :
PVC/PFA
Description

PFA/PVC Insulated and Sheathed E Type Thermocouple Extension Wire

TYPE E (CHROMEL vs Constantan) may be used in oxidizing, inert or dry reducing atmospheres, or for short periods of time under vacuum. Must be protected from sulfurous and marginally oxidizingatmospheres. Produces the highest EMF per degree o any standardized thermocouple.

1. Chemical Composition

Material Chemical composition (%)
Ni Cr Cu Mn Al
EP(Chromel) 90 10
EN(Constantan) 45 55

2. Physical properties and Mechnical properties

Material

Density(g/cm3)

Melting point℃)

Tensile Strength(Mpa)

Volume resistivity(μΩ.cm)

Elongation rate (%)
EP(Chromel) 8.5 1427 >490 70.6(20℃) >25
EN(Constantan) 8.8 1220 >390 49.0(20℃) >25

3. EMF Value range at different temperature

Material EMF value Vs Pt(μV)
100℃ 200℃ 300℃ 400℃ 500℃ 600℃
KP(Chromel) 2769~2859 5921~6019 9272~9374 12709~12819 16144~16282 19537~19699
EN(Constantan) 3499~3561 7389~7513 11647~11779 16109~16255 20699~20885 25362~25588

EMF value Vs Pt(μV)
700℃ 800℃ 900℃ 1000℃ 1100℃
22859~23043 26102~26308
30030~30292 34664~34960
