Non Magnetic FeCrAl Alloy 0.8 - 3.5mm Round Heating Wire For Nozzle Heaters
Non Magnetic FeCrAl Alloy 0.8 - 3.5mm Round Heating Wire For Nozzle Heaters
Non Magnetic FeCrAl Alloy 0.8 - 3.5mm Round Heating Wire For Nozzle Heaters
Non Magnetic FeCrAl Alloy 0.8 - 3.5mm Round Heating Wire For Nozzle Heaters
Non Magnetic FeCrAl Alloy 0.8 - 3.5mm Round Heating Wire For Nozzle Heaters
Non Magnetic FeCrAl Alloy 0.8 - 3.5mm Round Heating Wire For Nozzle Heaters
Specifications
Brand Name :
OHMALLOY
Model Number :
FeCrAl strip
Certification :
CE/ROHS/FCC/SGS
Place of Origin :
China(Shanghai)
MOQ :
30kg
Price :
negotiable
Payment Terms :
T/T or or L/C or Paypal
Supply Ability :
10000kg/month
Delivery Time :
Based on Quantity
Packaging Details :
In coils, then wooden case
Status :
Bright
Package :
30-50kg/coil
Application :
Braking resistor
Feature :
industry
Thickness :
0.8-3.5mm
Width :
20-300mm
Description

Non Magnetic FeCrAl Alloy 0.8 - 3.5mm Round Heating Wire For Nozzle Heaters

Item name

Aluchrom-O Bright FeCrAl 25 / 5 Alloy Strip For Resistor Capacitor​
Conductor Material 0Cr25Al5
Conductor Diameter 0.9mm+/-0.02
Condition Bright,half-hard/hard
Resistance value 2.23+-5% (2.12-2.34 )Ohm/m
Density 7.1g/cm3
Length/Kilo 221.5M/kg
Package Spool DIN 160,about 5kgs per spool
Standard GB/T 1234-12

Non Magnetic FeCrAl Alloy 0.8 - 3.5mm Round Heating Wire For Nozzle Heaters

0Cr25Al5 Normal composition%

C P S Mn Si Cr Ni Al Fe Other
Max
0.06 0.025 0.025 0.70 Max 0.60 23.0~26.0 Max 0.60 4.5~6.5 Bal. -

Typical Physical properties

Density (g/cm3) 7.10
Electrical resistivity at 20℃(Ωmm2/m) 1.42
Conductivity coefficient at 20℃ (WmK) 13

Coefficient of thermal expansion
Temperature Coefficient of Thermal Expansion x10-6/℃
20 ℃- 1000℃ 15

Specific heat capacity
Temperature 20℃
J/gK 0.46

Melting point (℃) 1500
Max continuous operating temperature in air (℃) 1250
Magnetic properties non-magnetic
