PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope
PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope
PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope
PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope
PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope
PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope
PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope
PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope
Specifications
Brand Name :
OHMALLOY/OEM
Model Number :
SP-2080-37Strands
Certification :
ISO9001：2015
Place of Origin :
China
MOQ :
500Meter
Price :
USD 1.02-2.58 per meter
Payment Terms :
L/C, T/T, ,Paypal
Supply Ability :
3000 KG per month
Delivery Time :
5-15 working days after payment confirmed
Packaging Details :
Spool+Plywood Case
Name :
Pure Nickel 200 19 Strands Wire Rope 500M/Roll PWHT Cold Tail Application
Wire Material :
Pure Nickel(nickel 200)
Wire Strands :
19 strands
Size :
19*0.574mm
Finished Diameter :
2.9mm
Application :
PWHT Ceramic Heating Pad Wire
Wire State :
Bright，Annealed
Pack Style :
500Meter/Roll
Description

Pure Nickel 200 19 Strands Wire Rope 500M/Roll PWHT Cold Tail Application

Specification
Item Name Pure Nickel 19 Strands Wire Rope PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope
Conductor Material Pure Nickel
Conductor Dia 19*0.574m m
Finished Diameter 2.9mm(+/-0.3mm)
Resistance 0.0198 ohm/meter (±5%)
Wire State Bright, Annealed
Package DIN250
Weight 500Meter/Spool


Product Name: 19 Strand pure nickel wire

Specification: 19*0.574mm

Outer Diameter: 2.9mm(±0.3mm)

Quantity: 5000 meter

Resistance: 0.0198 ohm/meter (±5%)

PWHT 2.9mm 500M/Roll 19 Strands Nickel 200 Wire Rope

Cable Diameter

Conductor Material

Number of Strands

King Wire Size

Resistance (Ohm/meter)

2.9mm

(±0.2mm)

Pure nickel (N953D10)

19*0.574mm (±0.015mm)

0.574mm (±0.015mm)

0.0198(+/-5%)
Qualified Qualified Qualified Qualified Qualified

Conductor Material Inspection: pure nickel Material Batch NO.: N953D10

Ni+Co S Si Cu C Mn Fe
≥99.5 <0.001 <0.01 0.045 0.026 <0.002 0.032

Wire Rope Type and Standard Size Reference:

Alloy Wire No. of Strands Nominal OD (mm) King Wire Size (mm) Resistance (Ω/m) Length (m/kg)
0Cr20Ni80 19*0.523 2.7 0.574 0.285 29
0Cr15Ni60 19*0.523 2.76 0.574 0.29 30
0Cr20Ni80 37*0.385 2.76 0.45 0.279 28
Pure Nickel 19*0.574 2.87 0.574 0.0198 21
Nickel 212 19*0.574 2.87 0.71 0.0234 22
