Specifications
Brand Name :
OHMALLOY/OEM
Model Number :
SP-3J53
Certification :
RoHS
Place of Origin :
Jiangsu
MOQ :
20KG
Payment Terms :
L/C, T/T
Supply Ability :
10 tons per month
Delivery Time :
15-28 working days after payment
Name :
42HXTЮ 3J53 Ni Span C Spring Permanent Magnetic Alloy Precision Elastic Parts Material
Material :
3J53（similar to Ni Span C902）
Density :
8.0 g/cm3
Supply Shape :
Bar/ Strip/ Wire
Treatment :
Aging Treatment
Resistivity :
1.1μΩ•m
Description

42HXTЮ 3J53 Ni Span C Spring Permanent Magnetic Alloy Precision Elastic Parts Material

3J53 is a constant elastic alloy used for making frequency components.

The main purpose:

Mainly used for various diaphragms, diaphragm boxes, bellows, springs and other elastic components in the instrument industry.

Main features:

High elasticity and strength, low elastic modulus temperature in the range of -60- + 100 ℃

Similar Brand to 3J53:

Russia American UK France Japan
42HXTЮ Ni-Span C902 Ni-Span C Ni-Span C Sumispan-3

3J53 Chemical Composition(%)

Grade C Si Mn P S Ni Fe Cr Ti Al
3J53 ≤0.05 ≤0.80 ≤0.80 ≤0.02 ≤0.02 41.5-43 Balance 5.2-5.8 2.3-2.7 0.5-0.8

3J53 Physical Property:

Density

(g/cm3)

 Resistivity (μΩ•m) Vickers-Hardness Modulus of Elasticity Shear Deformation
(HV) (E/MPa) (G/MPa)
8.0 1.1 350-450 176500-191000 63500-73500

3J53 Physical Property after Aging Treatment

Shape State Thickness/Diameter(mm) Tensile Strength(ᵟb/Mpa) Elongation≥(%)
Strip Cold Roll 0.2-2.5 1125 5
Annealed 0.2-1.00 1080 8
Wire Cold Draw 0.50-5.00 1375 5
Bar Cold Draw 3.0-18.0 1325 5
Round/Flat Hot Roll/Forge 6.0-25.0 1080 10

3J53 Supply Shape:

Shape Specification/mm Supply State
Bar 30.0-180.0 Hot forging
Strip 0.2-3.5 Cold Roll
Wire 0.1-5.0 Cold Draw

3J35 Application:

Tuning forks & Vibrating reeds

Leaf springs

Helical springs

Precision elastic parts

Diaphragms
