Galvanised Round Steel Wire Armour Polyethylene PE Insulation PVC Jacket For K Thermocouple
Galvanised Round Steel Wire Armour Polyethylene PE Insulation PVC Jacket For K Thermocouple
Galvanised Round Steel Wire Armour Polyethylene PE Insulation PVC Jacket For K Thermocouple
Galvanised Round Steel Wire Armour Polyethylene PE Insulation PVC Jacket For K Thermocouple
Specifications
Brand Name :
OHMALLOY
Model Number :
insulated wire
Certification :
ISO9001-2008
Place of Origin :
China(Shanghai）
MOQ :
100,meters
Price :
negotiable
Payment Terms :
L/C, T/T, , MoneyGram
Supply Ability :
500000 meter per month
Delivery Time :
7-10 days
Packaging Details :
in spool/ carton packed
Type :
K type thermocouple wire
Conductor material :
Positive Ni-Cr,Negative Ni-Al
Application :
Electrical equipment
Conductor type :
Strand or Solid
Insulation material :
Polyethylene PE
Color :
As per customers request
armour :
Galvanished round steel wire
Jacket :
PVC
Description

Galvanished Round Steel Wire Armour Polyethylene PE Insulation PVC Jacket For K Thermocouple

Conductor material:

Material Chemical composition(%)
Ni Al Cr Si Mn
Chromel 90 10
Alumel 95 1-2 1-2 0.5-1.5

Structure:

Conductor size 0.5mm
Inner Insulation material Polyethylene PE
Insulation layer thickness 0.2mm
Armour material Galvanished round steel wire
Armour thickness 0.2mm
Out jacket material PVC
Out jacket thickness 0.08mm

Remarks: The size can be changed if special requirement.

The thickness of insulation also can be adjusted by special requirement. We can do insulation thickness 0.2mm to 2.5mm

Calibration tolerance:+/-1.1 ℃ or +/-0.4%

Color code: ANSI 96.1 or IEC 584-2

Galvanised Round Steel Wire Armour Polyethylene PE Insulation PVC Jacket For K Thermocouple

Conductor Insulator Packing

sectional area

mm2

Conductor

Construction

NO. x φmm

Diameter

mm

Insulator

Thick

mm

Jacket

Thick

mm

Over

Diameter

mm

 Mt/coils
0.20 7x0.20 0.61 0.20 0.15 1.3X2.3 305
19x0.12 0.60 0.20 0.15 1.3X2.3 305
0.30 7x0.25 0.76 0.20 0.15 1.5X2.6 305
19x0.15 0.76 0.20 0.15 1.5X2.6 305
0.50 7x0.3 0.81 0.20 0.15 1.8X2.7 305
0.81 0.81 0.20 0.15 1.8X2.7 305
1.0 7x0.43 1.13 0.20 0.20 2.0X3.6 305
1.13 1.13 0.20 0.20 2.0X3.6 305
1.5 7x0.52 1.38 0.35 0.20 2.5X4.4 200
1.38 1.38 0.35 0.20 2.5X4.4 200
