Specifications
Brand Name :
OHMALLOY
Model Number :
Ohmalloy145
Certification :
ISO,SGS
Place of Origin :
China(Shanghai)
MOQ :
35kg
Price :
negotiable
Payment Terms :
T/T, , L/C
Supply Ability :
8000Kg/Week
Packaging Details :
Plastic packing inside, wooden box outside , choose the suitable packing, Alos it can be customized by the clients' demand.
Delivery Time :
5-8workdays
Resistivity :
1.45μΩ.m
Shape :
Wire
Surface :
Oxidized,Acid White
Application :
heating
Density :
7.1
Enamelled :
Available
Working Temperature :
1250
Description

Fe Base Heating Wire OCr21Al6Nb FeCrAl alloy 1mm~8mm heating resistance wire for braking resistor

Product Description

(Common Name:0Cr21Al6Nb, A,Alloy 835)

OhmAlloy145 is a iron-chromium-aluminium alloy (FeCrAl alloy) characterized by high resistance, low coefficient of electric resistance, high operating temperature, good corrosion resistance under high temperature.It is suitable for use at temperatures up to 1250°C.

FeCrAl-0Cr21Al6Nb alloy has the characteristic of high resistivity,low temperature resistance coefficient,high operating temperature,good anti-oxidation and anti-corrosion under high temperature.

It is widely used in industrial furnace, household appliances, industry furnace, metallurgy, machinery, aircraft, automotive, military and other industries producing heating elements and resistance elements.

1) Normal Composition(%)

C P S Mn Si Cr Ni Al Fe Other
Max
0.12 0.025 0.025 0.70 Max 1.0 18.0~21.0 Max 0.60 3.0~4.2 Bal. -

2)Typical Mechanical Properties(1.0mm)

Yield strength Tensile Strength Elongation
Mpa Mpa %
550 750 22

3)Typical Physical Properties

Density (g/cm3) 7.1
Electrical resistivity at 20ºC(Ωmm2/m) 1.45
Conductivity coefficient at 20ºC (WmK) 13

4)Coefficient of thermal expansion
Temperature Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC 16

Size dimension range:

Wire: 0.01-10mm

Ribbons: 0.05*0.2-2.0*6.0mm

Strip: 0.05*5.0-5.0*250mm

Bar:10-50mm

Other Popular FeCrAl alloy series: OCr15Al5,1Cr13Al4, 0Cr21Al4, 0Cr21Al6, 0Cr23Al5, 0Cr25Al5, 0Cr21Al6Nb,0Cr27Al7Mo2, and et

Production Process

Package

Testing Equirement

Customer Photos

3. Application

Packaging & Shipping

Exhibition

FAQ
