Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation
Specifications
Brand Name :
OHMALLOY
Model Number :
Enameled Copper Wire
Certification :
ISO CE ROSH
Place of Origin :
CHINA
MOQ :
1kg
Payment Terms :
L/C, T/T,
Supply Ability :
10000KG/week
Delivery Time :
10workdays
Packaging Details :
spool
Application :
Industry
Material :
Copper / Copper Alloy
Shape :
wire
Resistance (μω.m) :
Stable
certification :
ISO CE ROSH
model :
Enameled Copper Wire
Description

Colorful Sliver Plated Copper Wire Low MOQ Varnish Enameled Wire Good Electrical Conductivity Anti-oxidation

These enamel resistance lines have been widely used in standard resistance, high / low-voltage resistor vehicle components, winding resistors, and the like. Use the insulation treatment that best suits these applications to make full use of the unique features of the enamel coating.

In addition, we will carry out the noble metal tooth coating, such as silver and platinum wires on orders. Please use this production order.


Silver Plated Copper Based Alloys Varnish Enameled Anti Oxidation

Type of bare alloy wire

Copper-nickel alloy wire Pure copper, Constantan Wire,CuNi1,CuNi2,CuNi6~CuNi44 Resistance Wire,
Ni-Cr Alloy wire

Pure Nickel NiCr35/20,NiCr70/30,NiCr60/15,

NiCr80/20,NiCr90/10,NiCr AA,Karma.
Fe-Cr-Al Alloy wire

Cr13Al4,Cr21Al4,Cr21Al6,Cr23Al5,Cr25Al5,

Cr21Al6Nb,Cr27Al7Mo2,
Cu-Ni-Mn Alloy wire CuMn12Ni2,CuMn12Ni4,Manganin,NiMn2,
Any copper alloy and nickel alloy is available

Color of enameled insulation:

Red,Green,Yellow,Black,Blue,Nature etc.


Type of insulation

Insulation-enameled Name

Thermal Level℃

(working time 2000h)

 Code Name GB Code ANSI. TYPE
Polyurethane enameled wire 130 UEW QA MW75C
Polyester enameled wire 155 PEW QZ MW5C
Polyester-imide enameled wire 180 EIW QZY MW30C
Polyester-imide and polyamide-imide double coated enameled wire 200

EIWH

(DFWF)

 QZY/XY MW35C
Polyamide-imide enameled wire 220 AIW QXY MW81C

Style of supply

Alloys Name Type Dimension
Enameled-W Wire D=0.018mm~3mm
Enameled-R Ribbon W=0.4~24 T=0.01~0.2mm

FAQ
1. What's the minimum quantity customer can order?

If we have your size in stock, we can provide any quantity you want.

If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.

2. How can you pay for small sample amount?

We have account, wire transfer for sample amount also ok.

3. Customer do not have express account. How will us arrange the delivery for sample order?

Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.

4. What's our payment terms?

We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.

5. Do you provide free samples?

If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.

6. What's our working time?

We will give you reply through email/phone Online contact tool within 24 hours. No matter working day or holidays.
