Long Service Life Animal Feed Pellet Machine For Processing Animal Feed
Long Service Life Animal Feed Pellet Machine For Processing Animal Feed
Specifications
Brand Name :
AIX
Model Number :
SZLH350
Certification :
ce
Place of Origin :
china
MOQ :
1 set
Price :
USD5000-30000/set
Payment Terms :
L/C, , T/T, Western Union
Supply Ability :
300 sets per months
Delivery Time :
30days
Packaging Details :
woodencase or container
Name :
sheep feed making machine
Capacity :
2-7T/H
Application :
poultry farm,animal farm
Motor :
siemens
Funtion :
Producing Animal Feeds Pellets
Power :
55kw
Description

Automatic 1.5-12mm sheep feed making machine for processing animal feed

Sheep feed making machine can be used for making cattle, geese, pig, duck, chicken, sheep, rabbit, and other animals, livestock and poultry feed.The pellet size from 1.5-10mm.The pellet length can be adjusted. Pellet mill is the mainly machine of production the feed pellet,widely used in feed factory,animal farm,etc.

feed making machine can work with other machine to make one line.

The line:

Feed mixer----Feed crusher----Feed pellet mill----Feed pellet cooler----Feed packing machine

We can according to your detail requirement to supply you flowchart.

Main parameters:

Item Technical parameters and performance index
SZLH250 SZLH320 SZLH350 SZLH400 SZLH420 SZLH508
Capacity (t/h) 0.5-1 2-5 2-7 3-12 3-14 4-20

Power

(Kw)

 Main machine 15 37 55 75/90 90/110 110/132/160
Screw feeder 0.55 0.75 0.75 1.5 1.5 1.5
Conditioner 2.2 2.2 3 5.5 5.5 11
Inner diameter of die (mm) φ250mm φ320mm φ350mm φ400mm φ420mm φ508mm
Effective width of die (mm) 120mm 120mm 120mm 120mm 120mm 150mm

Rotary

(rpm)

 Die 328 328 328 248 248 248
Screw feeder 12-120 12-120 12-120 12-120 12-120 12-120
Conditioner 300 300 300 270 270 270
Pellet size (mm) φ2—φ10mm φ2—φ10mm φ2—φ10mm φ2—φ10mm φ2—φ10mm

φ2—

φ10mm


Features:

1. Feeding system of the Small Animal Feed Mill Plant adopts electromagnetic speed regulating control, speed control, convenient and full capacity to adapt to the different material requirement

2. Stainless steel conditioner,304 stainless steel,used for feed ripening,sterilization,improve,water resistance and outpu

3. Full stainless steel feeder,variable pitch anti-arch structure,imported FC control

4. The conditioner has double layer,three layer folder or double track conditioner to meet different meeds of producing high grade livestock and poultry feed and aqua feed.

5. Imported gear box,high processing accuracy,high transmission efficiency,low energy consumption

304 stainless steel ring die,corrosion resistance, full automatic CNC ring die drilling machine and vacuum heat treatment technology

6. Scraper panel assembly,equipped with hard alloy knife,which improves service life,and cut surface quality.
