Multi - Function Corn Hammer Mill Crusher , Cyclone 22kw Cattle Feed Grinder
Multi - Function Corn Hammer Mill Crusher , Cyclone 22kw Cattle Feed Grinder
Multi - Function Corn Hammer Mill Crusher , Cyclone 22kw Cattle Feed Grinder
Multi - Function Corn Hammer Mill Crusher , Cyclone 22kw Cattle Feed Grinder
Multi - Function Corn Hammer Mill Crusher , Cyclone 22kw Cattle Feed Grinder
Multi - Function Corn Hammer Mill Crusher , Cyclone 22kw Cattle Feed Grinder
Multi - Function Corn Hammer Mill Crusher , Cyclone 22kw Cattle Feed Grinder
Multi - Function Corn Hammer Mill Crusher , Cyclone 22kw Cattle Feed Grinder
Specifications
Brand Name :
Strongwin
Model Number :
FS50-40
Certification :
CE,ISO,SGS
Place of Origin :
China
MOQ :
one set
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
6000 sets per year
Delivery Time :
3-7 working days after deposit
Packaging Details :
Wooden Case or In Container
Name :
Multi-function Corn Hammer Mill Feed Grinder Machine With Cyclone
Capacity :
600-800kg/h
Inlet size :
400*280mm
Power :
22kw
Weight :
300kg
Dimension :
1400*780*1250mm
Feature :
With Cyclone
Application :
Feed and Grass crusher
Description

Multi-Function Corn Hammer Mill Feed Grinder Machine With Cyclone

Before crushing , it is important to make sure the suitable feeding size , in other words , the suitable size of raw material is less than 50mm

The moisture content of raw material is 10-25%

1.Features of hammer mill feed grinder machine:

Hammer mill is the specified machinery which is designed and invented for many years according to the demand of industrial production development.

It has the advantages of reasonable design, compact structure, safe, wear resistant, high production efficiency, etc. Whole machine only driven by one motor, low noise, simple structure, compact assemble, low price, reliable performance, low power consumption, high capacity, good quality of final products and low production cost,etc.

2. working principle of hammer mill feed grinder machine:

Hammer mill adopts the integrated function of hammer hitting grinding, as well as the air current shocking.

Meanwhile,it can do the screening process of fine material. In the process of hammer hitting,rotor can have high speed air current and move along with the hammer hitting,the material will be dual grinded in the hitting, so it can promote the grinding efficiency of material.

3. Main application:

It can crush the branch and limb which diameter is very small, such as wheat, corn, rice husk, cornstalk, etc.

Technical Parameters of hammer mill feed grinder machine

Model power(kw) capacity(kg/h) dimension(mm) weight(kg) Inlet size
FS50-28 11 500-600 1250*650*1000 150 280*250
FS50-40 22 600-800 1400*780*1250 300 400*280
FS60-6 30+7.5 1000-1200 1750*900*1550 900 600*350
FS80-8 55+11 2000-2500 2200*1780*1500 1100 800*380
