Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed
Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed
Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed
Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed
Specifications
Brand Name :
Strongwin
Model Number :
1.5-2.5t/h feed plant
Certification :
CE,ISO
Place of Origin :
Henan,China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 sets per year
Delivery Time :
15-30 working days
Packaging Details :
whole production line:by container
Name :
Kenya 2 T/H Poultry Feed Manufacturing Process Equipment
Voltage :
380V/50Hz
Power :
60KW
Capacity :
2t/h
Type :
Belt type
Feed size :
2-15mm
Service :
24 hours online technical support
Installation :
Offer manual book and engineer's guidance
Description

Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed

Introduction of Poultry Feed Manufacturing Process Equipment

Animal feed pellet process plant is a complete set of machines that are specifically used to make feed pellets.

The machine group generally including the following process: Raw materials receiving and cleaning process, Crushing process, Mixing process, Pellet making process, Pellet cooling process, (pellet crumbling process), Sifting process and Packaging process.

The feed plant widely used to produce pellets for animals,such as chicken, duck, Pigeon, pig, horse, cattle sheep and other poultry and livestock animal. The pellets by our machine have firm and smooth structure and easy digest

Belt Type 2T/H Poultry Pellet Feed Plant 60KW 15mm Feed

Technical Parameters of Poultry Feed Manufacturing Process Equipment

No. Product Type Power(KW)
1.Raw materials receiving and crushing and mixing system
101-1 Screw Conveyor TLSS16 2.2
101-2 Screw Conveyor TLSS20 3
103 Imitation grinder (including iron remover) SFPZ56*30 18.5
104 U-shaped ribbon horizontal mixer LHY1.0 7.5
2.Pelleting system
201 Screw Conveyor TLSS20 3
202 To be granulated bin (including window) 1.0m³
203 Pellet Machine(include control box) SZLH250 11*2+2.2+0.75
3.Cooling system
301 Skirt belt conveyor QBPS400 2.2
302 Buffer bucket 0.2m³
303 Stainless steel air shutter GFY250 1.1
304 Counter Flow Cooler SKLN1.0 0.75
305 Air Blower 4-72No4A 5.5
306 Unloader XL60
307 Wind shut GFY215 0.75
308 Vibrating screen SFJZ60*1d 0.25
4.Screening and packaging system
401 Skirt belt conveyor QBPS400 2.2
402 Buffer bucket 0.5m³
403 Packing scale with sewing bag 2.2
Optional Simple oil filling system (including pipes and nozzles) SYVT32 1.5
Air compression system 3
Boiler with link system 0.3t/h 3
Crumbler machine SSLG15×80 5.5
Price Welcome contact us for latest price
