Chicken Animal Granulated Pellet Production Plant 3T/H
Chicken Animal Granulated Pellet Production Plant 3T/H
Chicken Animal Granulated Pellet Production Plant 3T/H
Chicken Animal Granulated Pellet Production Plant 3T/H
Specifications
Brand Name :
Strongwin
Model Number :
SZLH350
Certification :
CE,ISO,SGS
Place of Origin :
China
MOQ :
one set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 sets per year
Delivery Time :
7-10 working days
Packaging Details :
Wooden Case
Equipment name :
Complete set feed pellet line
Capacity :
3-5T/H
Power :
230KW
Type :
SZLH350 Ring die
Main machine :
crusher,mixer,pellet,cooler,crumbler,screener,packing machine
Pellet size :
2-15mm
Apply to :
Kinds of poultry livestock animal feed
Description

Chicken Animal Granulated Feed Production Line Price 3Tn/Hour

Animal feed pellet production line introduction

Animal feed pellet line is a complete set of machines that are specifically used to make feed pellets.

The machine group generally including the following process: Raw materials receiving and cleaning process, Crushing process, Mixing process, Pellet making process, Pellet cooling process, (pellet crumbling process), Sifting process and Packaging process.

Technical parameters of Animal feed pellet production line

NO. Name Model Qty Power(KW)
Section1. System of receiving&cleaning & grinding of raw material
11 Grass crusher FSP500B-22 1 22
111 Hammer mill SDH-ZW29C 1 55
113 Air blower 4-30No4A 1 7.5
114 Pulse dust collector TBLMa36 1
116 Seal Screw conveyor TLSB20 1 2.2
Section2:System batching&mixing
202 Bucket elevator TDTG36/28 1 4
203 Rotary Distributor TFPX-6(250) 1 0.75
211 Double shaft blade mixer SLHY1.0 1 11
214 Scraper conveyor TGSU20 1 3
Section3:System of pelleting & cooling
308 Buffer hopper 1
309 Pellet machine SZLH350 1 59.5
312 Counter flow cooler SKLN4 1 1.1
313 Pellet crushing SSLG15×100 1 5.5
314 Air blower 4-72-5A 1 11
Section4:System of packing
401 Bucket elevator TDTG36/18 1 3
402 Rotary screen SFJH100*2d 1 2.2
408 Buffer hopper 0.5m³ 1
409 Automatic Packing scale 10-50KG 1 1.5
410 Sealer & conveyor 1 1.5
Section5:System of Auxiliary(Optional)
501 Air compressor 1 15
502 Steam supply system 1
503 Liquid adding machine 1 2.2
504 Electricity Hoist 1 2.2

Chicken Animal Granulated Pellet Production Plant 3T/H

Chicken Animal Granulated Pellet Production Plant 3T/H

SZLH350 feed equipment is widely used to produce pellets for animals,such as carp, chicken, pig, horse, cattle and other poultry and livestock animal. The pellets by our machine have firm and smooth structure and easy digest.Since now our machines have exported to Mali, Zambia, South Korea, Russia, Oman, Thailand, Bangladesh and so on.Some customers bought a single machine, and most customers bought a production line to found a feed making factory.

Welcome contact us for more information !
