250kg/H 90KW Extruded Marine Fish Feed Production Line
250kg/H 90KW Extruded Marine Fish Feed Production Line
250kg/H 90KW Extruded Marine Fish Feed Production Line
250kg/H 90KW Extruded Marine Fish Feed Production Line
250kg/H 90KW Extruded Marine Fish Feed Production Line
250kg/H 90KW Extruded Marine Fish Feed Production Line
250kg/H 90KW Extruded Marine Fish Feed Production Line
250kg/H 90KW Extruded Marine Fish Feed Production Line
Specifications
Brand Name :
Strongwin
Model Number :
DGP80B
Certification :
CE,ISO,SGS
Place of Origin :
China
MOQ :
one set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000sets per year
Delivery Time :
7-10 working days
Packaging Details :
Wooden Case
Name :
Fish Feed Mill Extruder Plant Dog Food Production Line
Main machine :
Crusher, mixer,extruder,dryer,spary, cooler,packing machine
Power :
90KW
Capacity :
200-250kg/h
Application :
Fish shrimp feed, pet food
Service :
From design to installation
Description

DGP80B 90KW Fish Feed Mill Extruder Plant Dog Food Production Line

Introduction of fish feed extruder plant

Floating fish feed plant is applicable to produce feed pellets for pet, ornamental fish,
pond-fish, and marine fish, such as catfish, shrimps, crab etc. According to the
nutritional requirements of different fish species, consumers can readjust the process, add
different raw materials and manufacture a variety of fish feeds with different particle
sizes and properties of floating-up. Fish feed pellets, produced after high temperature and
high pressure, pollute less in the feeding process.

250kg/H 90KW Extruded Marine Fish Feed Production Line

Process of fish feed extruder plant

Material grinding→material mixing→extruding process→pellets drying→oil spraying process→pellets cooling→pellet packing

Technical Parameters of fish feed extruder plant

NameCapacityPowerDimension
Crusher300-400kg/h11kw1350*930*1250mm
Dusting collection, bag dust collector and storage binCapacity of storage bin 0.5-1.0m³0.75kw*21200*1000*3200mm
Screw elevator300-400kg/h1.5kw3000*820*630mm
Horizontal mixer100kg/batch,every batch is 10min.3kw1530*820*1420mm
Screw elevator300-400kg/h1.5kw3000*820*630mm
Extruder
DGP80-B		200-300kg/hMain Power:
22kw
Cutting Power:
0.6kw
Feeding Power:
0.8kw		1800*1550*1300mm
Air conveyor200-400kg/hFan power: 2.2kw
Discharge power: 0.75kw		750*650*1850mm
Mesh belt dryer200-300kg/hHeating power:
24kw
Mesh Belt Power:
2.2kw
Fan Power:
0.55kw		3200*1200*1850mm
Air conveyor200-400kg/hFan power: 2.2kw
Discharge power: 0.75kw		750*650*1850mm
Spraying Machine300-500kg/hMain Power: 0.75kw
Oil Pump Power: 0.37kw		5000*750*1550mm
Air conveyor200-400kg/hFan power: 2.2kw
Discharge power: 0.75kw		750*650*1850mm
Counter current cooler100-150kg/batch,10- 15min3kw1150*900*2000mm
Air conveyor200-400kg/hFan power: 2.2kw
Discharge power: 0.75kw		750*650*1850mm
Packing scale≤300 bag/h.
1-25kg/bag		0.75kw2650*800*2740mm
Power control system


250kg/H 90KW Extruded Marine Fish Feed Production Line

Our factory supply dry and wet type fish feed extruder plant
Provide users with economical and rational design
Professional installation and training service

Welcome contact us !
