Specifications
Brand Name :
Strongwin
Model Number :
5t/h pellet plant
Certification :
CE,ISO,SGS
Place of Origin :
China
MOQ :
one set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 sets per year
Delivery Time :
15-30 working days after deposit
Packaging Details :
Wooden Case or In Container
Type :
Automatic Poultry Feed Pellet Production Plant With Control System
Yield :
5T/H
Final pellet :
2-10mm
Main machine Power :
300kw
Main machine :
crusher,mixer,pellet,cooler,screener machine
Application :
Animal Feed Factory
Motor :
Siemens
Bearing :
SKF
Description

Automatic Feed Pellet Production Plant , Poultry Feed Processing Machine With Control System

Our factory supply turnkey project for Customers

Introduction of Poultry Feed Pellet Production Plant(detail machine)

Water-drop hammer crusher machine

With full open operating door, elasticity sieve pressing mechanism, easy to maintain and replace sieve.

Double shaft paddle mixer

The improvement of open door shaft and link mechanism ensure that the angle of openning door is larger than 90-(the materials can’t fall on the door), close door which is deadlocked.

Ring die feed pellet machine

Ring die pellet machine main engine drives, high precision gear, ring die in quick detaching encircling hoop type, output higher 20% than belt drive

Larger type strengthen feeding conditioner in entire stainless steel with frequency speed control, ensure the high quality of pellet feed.

Counter-flow cooler machine

Eight corner structure without residue

High temperature resistance of Inspection window

Direct type reducer, Motor with emergency stop

Screener machine

Low breakdown, less maintenance, simple operation, the gearbox adopts non-gear transmission way, dispense with oil lubrication, avoid oil pollution with oil leakage

It changes the tail sliding support into elastic support, avoid deposited material avoid cross contamination

Electric control cabinet system, easy to operate and reasonable price

Technical Parameters of Poultry Feed Pellet Production Plant

Item Name Type Qty Power (KW)
Part 1. Raw material receiving& crushing system
1 Grass crusher FSP500B-22 1 22
1-103 Impulse Filter TBGM20 1
1-105 Bucket Elevator TDTG36/23 1 4
1-106 Cylinder Filtering Sieve TCQY63 1 0.75
1-107 Additive Blender TCXT20 1
1-110 Impeller speed regulating Feeder SWLY60 1 1.1
1-111 Crusher SFSP66*60 1 55
1-114 Impulse Filter TBLMa24 1
1-116 Wind-shielding Screw conveyor TLSB20 1 2.2
Part 2. Mixing System
2-202 Bucket Elevator TDTG36/23 1 4
2-203 Powder Screener SCQZ60 1 5.5
2-207 Feeder for additive 1
2-208 Mixer SLHS1.0 1 11
2-210 Scraper Conveyor TGSU20 1 3
Part 3. pelleting system
3-308 Pellet Mill SZLH350 1 57.95
3-310 Cooler SKLN3 1 1.5
Part 4. Packing system
4-401 Bucket elevator TDTG36/18 1 3
4-402 Rotary Screener SFJH80*2d 1 2.2
4-409 Auto Packing Scale 10-50KG 1 1.5
4-410 Stitch conveyor 1 1.5
Part 5. Auxiliary Equipment System
5-506 Steam Supplying System 1
5-507 Oil adding System 1 2.2
5-508 Oil Adding Tube 1
5-509 Calabash Crane 1 3
