Specifications
Brand Name :
Strongwin
Model Number :
SZLH250
Certification :
CE,ISO,SGS
Place of Origin :
China
MOQ :
one set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100sets per Months
Delivery Time :
3-7 Working days
Packaging Details :
Wooden Case
Product Name :
Pellet Feed Making Machine Chicken Feed Pellet Machine For Kenya Farm
Capacity :
1.5-2.5t/h
Raw materials :
soybean,maize,corn, grain,sorghum etc
Application :
Poultry chicken feed
Main Motor Power :
22kw
Conditioner Motor Power :
1.5kw
Pellet Size :
1.5-12mm
Motor :
Siemens
Description

Pellet Feed Making Machine Chicken Feed Pellet Machine For Kenya Farm

Brief Introduction of Chicken Feed Pellet Machine

Strongwin Manufacture SZLH250(capacity is 1.5-2.5t/h) ring die feed pellet machine. Can be single used or apply to animal feed pellet line.

Which Can Make pellets for chicken, bird, duck, rabbit, pig, cattle, cow, sheep, horse etc. If Customers materials have grass, The machine also can equipped with force-feeding device.

Advantages of SZLH250 Chicken Feed Pellet Machine

1. High efficiency

Stable and classical gear driving, non-slipping, can really ensure the production output. Low noise, optimized ring die, maximum output.

2. Hygiene and safety

CE certified standard design and available stainless conditioner for feed, human and machine safety.

3. Flexible production

Wide product rangeΦ1.5mm-Φ12mm pellets, conditioner with molasses and steam adding function.

4. Friendly operation

Hydraulic system for ring die change and roller adjustment(optional), quick ad precise operation; auto-lubrication system(optional)and die & roller lifting device, save labor; on-site touch screen control.

Technical Parameters of Chicken Feed Pellet Machine

Items Technical Parameter (SZLH250)
Production Capacity 1.5-2.5t/h
Power of Main Motor 380V 50Hz 3 Phase 22 KW (Can be customized)
Power of Feeding Screw Motor 0.75 KW
Power of Conditioner 1.5 KW
Inner Diameter of ring die Φ250mm
Efficient width of ring die 80mm
Speed of ring die 300rpm
Speed of feeding screw 12-120rpm
Speed of Conditioner 350rpm
Pellet specification φ2,φ3,φ4,φ4.5,φ5,φ6,φ8,φ10mm
Amount of roller 2
Diameter of Roller Φ110mm
Pellet Ratio of Briquetting ≥ 95%
Percentage of powdered Pellet ≤12%
Stability of pellet in the water ≥20min
Noise ≤85dB(A)
Working temperature of ring die ≤85℃
Working pressure of steam 0.3Mpa
Steam consumption 50kg/H
Temperature of steam 130-150℃
Packing Size (length×width×height) 2450*1550*2200mm
Machine Size 2250*1430*2040mm
Net/Gross Weight 1150KG/1445kg

1.5 - 12mm Pellet Size Chicken Feed Pellet Machine High Efficiency For Farm
