Siemens Motor Low Noise Hammer Mill Crusher For Concentrate Chicken Feed
Siemens Motor Low Noise Hammer Mill Crusher For Concentrate Chicken Feed
Siemens Motor Low Noise Hammer Mill Crusher For Concentrate Chicken Feed
Siemens Motor Low Noise Hammer Mill Crusher For Concentrate Chicken Feed
Siemens Motor Low Noise Hammer Mill Crusher For Concentrate Chicken Feed
Siemens Motor Low Noise Hammer Mill Crusher For Concentrate Chicken Feed
Specifications
Brand Name :
FAR
Model Number :
SFSP998
Certification :
CE ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
50 sets per year
Delivery Time :
30 days
Packaging Details :
iron pallet
Output :
10-50tph
Dia. of Rotor :
1200mm
Power :
55-200kw
Voltage :
380V
Bearing :
SKF
Motor :
Siemens
Warranty :
1 Year
Weight :
600kg
Description

Siemens Motor Low Noise Hammer Mill Crusher For Concentrate Chicken Feed

Product Description

Features of Hammer Mill Powder:
1. The grinding chamber is of tear circle shape, effectively eliminating the circular flow in the grinding process and getting higher capacity;
2. The bottom of grinding chamber is fitted with U-shape double grinding structure, further improving the capacity with evener particle size;
3. All of our rotors pass an accurate dynamic balancing test, resulting in low noise and smooth running.
4. Both coarse and fine grinding can be completed by adjusting the distance between the beater and the screen;
5. New type S-shape coupling directly connecting driving results in big offset travel and effectively avoid the heating of bearing;
6. Beater blade edge is vacuum-welded by special alloy steel, resulting in long service life;
7. The imported components are used for key parts, resulting in long service life and low maintenance cost.;
8. The moving full-wide operation door facilitates maintenance and replacing of beater;
9. It is widely used in various feed mills, oil plants, alcohol plants, citric acid plants, etc.

Main Technical Parameters of Corn Grinder Machine:

Model
Parameters

SFSP998-1

SFSP998-2

SFSP998-3

SFSP998-4

Dia. Of Rotor(mm)

1200

1200

1200

1200

Width Of Grinding Chamber (mm)

300

400

500

600

Speed Of Rotor(rpm)

1480

1480

1480

1480

Power(kw)

55/75

90/110

132/160

200/220

Output(t/h)

10-15

12-20

25-35

38-50

Re: The above indexes are those when meeting the following conditions: raw material: corn, moisture content not higher than 14%, density not lower than 0.72t/m3, screen: hole diameter 3mm, hole-opening rate not less than 33%.
