Ring Die Poultry Animal Feed Pellet Machine 380V For Manufacture Plant
Ring Die Poultry Animal Feed Pellet Machine 380V For Manufacture Plant
Ring Die Poultry Animal Feed Pellet Machine 380V For Manufacture Plant
Ring Die Poultry Animal Feed Pellet Machine 380V For Manufacture Plant
Specifications
Brand Name :
Shenghong
Model Number :
SZLH250
Certification :
BV, SGS, ISO9001, CE
Place of Origin :
Henan, China
MOQ :
1 Piece
Price :
USD 5999-29999
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
20 sets per month
Delivery Time :
within 15 days
Packaging Details :
20GP, 40GP, 40HQ
Product name :
Ring Die Poultry Animal Feed Pellet Machine For Manufacture Plant
Raw material :
Carbon steel
Dimension :
3260*1100*2200mm
Voltage :
380V, 50hz, 3 phase
Screw diameter :
155mm
Application :
Animal feed pellet machine
Description

Ring Die Poultry Animal Feed Pellet Machine For Manufacture Plant

Product description

SZLH ring die type animal feed pellet machine mainly using for poultry feed pellets making, this machine with constant speed feeder, and connecting with a conditioner, the conditioner can connecting with steam for softens and ripens materials, make the final pellets good for animal health.
This ring die livestock pelletizer, with big ring die and big roller structure, high capacity and easy operating. The pelleting chamber cover easy opening, it is good for normallly maintanence and change the ring die and rollers.

Parameter
Raw materials corn,wheat bran,fish meal,bone powder,meat,alfafa,grassetc.
Diameter of feed pellet 2/2.5/3/3.5/4/6/8/10mm
Application feed pellet machine/plant widely be used for home,poultry and livestock farm.
Capacity 1-3T/H,also can customized according to your demand
Process Step crushing-mixing-pelletizing--cooler&screener--packing
Warranty 1Year(except spare parts)
Certication CE
Motor Siemens Brand Motor
Bearing Brand
Service after sales Engineer can provide technical support
Model Main power(kw) Out-put(t/h) Power of Conditioner(kw) Power of screw feeder(kw) In-side of rind die(mm)
SZLH250 22 0.5-1.5 2.2 0.55 250
SZLH320 37 2-3 2.2 0.75 320
SZLH350 55 3-5 3 0.75 350
SZLH400 75/90 3-10 5.5 1.5 400
SZLH420 90/110 3-14 5.5 1.5 420
SZLH508 110/132/160 6-15 7.5 2.2 508
SZLH558 180/200 10-20 11 2.2 558
SZLH678 220/250 25-30 18.5 3 678
Feature:

Ring die pellet mill is specially designed for mass industrial production of animal feed pellets . The raw materials are easy to obtain, like corn/wheat/soybean . The final pellets can be used for feed pellets and Cat litter particles.
Application: for making cattle, geese, pig, duck, chicken, sheep, rabbit, and other animals, livestock and poultry feed. You can make 2-8 mm diameter animal feed pellets. Such as 2-4mm diameter chick feed pellets and pig feed pellets.2-5mm rabbit feed pellet, 4-8mm cattle or sheep feed pellets.

The ring die type animal feed pellet machine mainly using for poultry feed pellets making, this machine with constant speed feeder, and connecting with a conditioner, the conditioner can connecting with steam for softens and ripens materials, make the final pellets good for animal health.

Function of each part:

1) Feeder: feeding raw material into the conditioner.
2) Conditioner: the feed raw material are ripened and sterilized due to the vapour steam. which can improve the digestibility of the feed, promote the absorption, increase the feed meat ratio and reduce the production cost.
3) Vapour steam inlet: connection with steam boiler.
4) Pellet making: ring die and press roller inside work together to make the raw material into pellet pellet.
5) Main motor: driving the pellet making system.

Ring Die Poultry Animal Feed Pellet Machine 380V For Manufacture Plant
Application:
Application: for making cattle, geese, pig, duck, chicken, sheep, rabbit, and other animals, livestock and poultry feed. You can make 2-8 mm diameter animal feed pellets. Such as 2-4mm diameter chick feed pellets and pig feed pellets.2-5mm rabbit feed pellet, 4-8mm cattle or sheep feed pellets.

Ring Die Poultry Animal Feed Pellet Machine 380V For Manufacture Plant
