Sheep Auto Ring Die Feed Pellet Mill Machine For Animal Feed
Sheep Auto Ring Die Feed Pellet Mill Machine For Animal Feed
Sheep Auto Ring Die Feed Pellet Mill Machine For Animal Feed
Sheep Auto Ring Die Feed Pellet Mill Machine For Animal Feed
Specifications
Brand Name :
Shenghong
Model Number :
SZLH420
Certification :
BV, SGS, ISO9001
Place of Origin :
Henan Province China
MOQ :
1 Piece
Price :
USD 3999-6999
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
20 sets per month
Delivery Time :
within 10 days
Packaging Details :
Plywood packing, 20GP, 40GP, 40HQ
Product name :
Automatic Ring Die Feed Pellet Mill Machine For Making Animal Sheep Feeds
Material :
Carbon steel
Dimension :
2100× 2000× 1850mm
Application :
Feed machine
Function :
Producing Pellets
Voltage :
380V 50HZ 3phase
Description

Automatic Ring Die Feed Pellet Mill Machine For Making Animal Sheep Feeds

Advantages of animal feed pellet mill machine

1. Poultry Feed Pellet Mill Feeder
The feeder consists of speed-adjusting motor, reducer, screw hopper, and screw oar.
2. Animal Feed Pellets Process Machine Conditioner
The conditioner is mainly made up of carbon steel or full stainless steel, mix oar, temperature display, motor and steam adding hole.
Its function is passing 0.10.4Mpa dry steam to make steam and feedstuff mix enough, to make material soft and pasted then goes into the pressing store.
The mixer hopper, mixer axis and oar are all made of carbon steel or stainless steel, so it is propitious to working in high-temperature and high-humidity environment.
3. Animal Feed Pellets Process Machine The pressing store
Through the cover of ring die and feeder scraper, the powder material accumulate in the two pressing districts, belt wheel drives the ring-die rotate, the material is rolled between the ring-die and the pressed roller, two opposite
rotating parts press the material gradually into the hole of ring die, shaped in the hole and extrude out of the hole, knives by the column strip in the length you need, finally the shaped pellets roll out of the machine.
The axis of pressed roller is eccentricity running it will change the gap between die and roller, the gap-adjusting completes through running the wheel.
4. The security system The security system is made up of overload protection, the pressing store door and cover, anti-operation trip switch and outflow from the machine.
a. Grains Feed Pellet Making Machine Overload protection
When hard impurity into pressing district or flow of material is too big, pressure between ring-die and pressed roller is over normal,
Spindle bear torque above normal and Shear stress which Pass safety pin is also above ultimate strength, then safety pin broken, making spindle spline block rotate and touch trip switch to stop.
b. Corn Feed Pellet Press MachineMachine Mill Door and cover protection switch During working, to avoid unnecessary casualties because of high speed rotating when open the door and cover of the pressing store, then install a security trip switch on the left side of the door and cover. When open the door and cover, the trip switch break control circuit of the pellet mill to make the pellet mill stop or can not start up to keep people safe.

Parameter of animal feed pellet mill machine

Model
SZLH250
SZLH320
SZLH350
SZLH420
SZLH508
Power(KW)
22
37
55
110
160
Capacity(T/H)
1
2-4
5-7
8-10
15-20
Inner dia(mm)
250
320
350
420
508
Pellet size(mm)
2-8
2-8
2-18
2-18
2-18

Sheep Auto Ring Die Feed Pellet Mill Machine For Animal Feed
Features of feed pellet mill machine
1) High precision gear driving is adopted, resulting in high driving efficiency and stable working.
2) The feed pellet machine is fitted with deranging and overload protection device and protection on the machine is fully considered during the operation.
3) It can be fitted with single-layer, multiple-layer jacket conditioners or double-shaft differential conditioner so as to meet the different requirements of producing high grade livestock and poultry feed and aqua feed.

Sheep Auto Ring Die Feed Pellet Mill Machine For Animal Feed
Our service
1) We are the professional manufacturer, which has abundant experience of the machine, also we own research and development team.
2) The professional and timely 24 hours after-sale service.
3) The relative manual and video of the machine installation and instruction will be provided for you.
4) ODM&OEM Provided.
5) The engineer is available to install and training for oversea projects.
