High Voltage 800VDC 2P FEEO DC MCB For Solar PV
High Voltage 800VDC 2P FEEO DC MCB For Solar PV
High Voltage 800VDC 2P FEEO DC MCB For Solar PV
High Voltage 800VDC 2P FEEO DC MCB For Solar PV
Specifications
Brand Name :
FEEO
Model Number :
FPV-125
Certification :
CE/TUV/CCC/RoHS
Place of Origin :
China
MOQ :
1PC
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000pcs per week
Delivery Time :
7days
Packaging Details :
120pcs per carton
Pole :
2P
Rated Current :
63-125A
Rated Operating Voltage :
800VDC
Rated Impact Voltage :
4KV
Ultimate Breaking Capacity :
10KA
Run Breaking Capacity :
75%
Curve Type :
C
Trip Type :
Thermal-magnetic
Description

800VDC 63-125A 2P Auto Circuit Breaker High Voltage Circuit Breaker

FPV-125 high breaking capacity circuit breaker is specially for solar PV

system. The current is form 63A to 125A and voltage up to 1000VDC.

Standard according to IEC/EN60947-2.

Specifications

Rated current 63,80,100,125A
Rated Voltage 250VDC 550V/800VDC 750VDC 1000VDC
No. of Poles 1P 2P 3P 4P
Machanical Life 20000 times(C.O.)
Electric Life 20000 times(C.O.) 125A:10000 times(C.O.)
Icu 10kA
Ics 63A,80A,100A :10kA 125A : 7.5kA
Weight 150 300 460 620

Dimension

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

Installation

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

Over current tripping characteristic

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

Current correction values used at different ambient temperatures

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

Current correction factor used at different altitudes
Rated Current
Different altitude correction factors
≤2000m
2000~3000m
≥3000m
3,6,10,16,20,25,32,40,50,63A
 1.0 0.9 0.8

Characteristic Curve

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

Application

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

High Voltage 800VDC 2P FEEO DC MCB For Solar PV

High Voltage 800VDC 2P FEEO DC MCB For Solar PV
