FE7-63 3P AC Power Circuit Breaker 10KA 400VAC For Lighting Distribution
FE7-63 3P AC Power Circuit Breaker 10KA 400VAC For Lighting Distribution
FE7-63 3P AC Power Circuit Breaker 10KA 400VAC For Lighting Distribution
FE7-63 3P AC Power Circuit Breaker 10KA 400VAC For Lighting Distribution
FE7-63 3P AC Power Circuit Breaker 10KA 400VAC For Lighting Distribution
FE7-63 3P AC Power Circuit Breaker 10KA 400VAC For Lighting Distribution
FE7-63 3P AC Power Circuit Breaker 10KA 400VAC For Lighting Distribution
FE7-63 3P AC Power Circuit Breaker 10KA 400VAC For Lighting Distribution
Specifications
Brand Name :
FEEO
Model Number :
FE7-63
Certification :
CE
Place of Origin :
China
MOQ :
1 pc
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
7000 pcs per week
Delivery Time :
7days
Packaging Details :
47*23.5*18CM
Color :
White
Certificates :
CE
Voltage :
400V
Current :
63A
Description

3p amps miniature circuit breaker

Product Description

FE7-63 MCB is used in lighting distribution system or motor distribution system for protecting overload and short circuit in the systems.

2)This product is novel in structure, light in weight, reliable and excellent in performance.

3)It has high breaking capacity and can trip quickly. Its case and body are made of highly fire-retardant and shockproof plastic.
4)This product, with long life, is mainly used in AC 50Hz / 60Hz single-pole 240V or
two / three / four-pole 415V circuit for overload and short circuit protection, as well as infrequent on-and-off switching electric equipment

and lighting circuit in normal cases. This product conforms to GB10963 and IEC60898 standards.

miniature circuit braker Technical Date:

Item MINI CIRCUIT BREAKER
Code FE7-63
Pole 1P 2P 3P 4P
Current 1A,3A,6A,10A,16A,20A,32A,40,50A,63A
Voltage 250v/450v
Standard IEC/EN60898
Breaking Capacity 6KA,10KA
Characteristic Curve B,C,D
Working Temperature “-5°”to +40°
Protection Degree IP20
Electrical life More than 8000times
Mechanical life More than 2000times
Dimension(W)X(H)X(D) 18X80X71 36X80X71 54X80X71 72X80X71
Installation 35MM DIN RAIL
Accessory YES
Installation Altitude ≤2000M

1. The upper limit of ambient air temperature should not exceed +40℃, the lower limit should not be lower than -5℃, and the average temperature of 24 hours should not exceed +35℃;
Note 1: The lower limit is -10°C or -25°C working conditions, the user must declare to the manufacturer when ordering;
Note 2: For working conditions where the upper limit exceeds +40°C or the lower limit is lower than -25°C, the user should negotiate with the manufacturer.
2. The altitude of the installation site does not exceed 2000m;
3. The relative humidity of the atmosphere does not exceed 50% when the ambient air temperature is +40℃. Higher relative humidity can be allowed at a lower temperature, for example, it can reach 90% at +20℃. Appropriate measures should be taken for condensation;
4. Pollution level: Level 2;
5. Installation category: Type Ⅱ and Type Ⅲ;
6. The external magnetic field of the installation site should not exceed 5 times the geomagnetic field in any direction;
7. Generally installed vertically, with a tolerance of 2° in any direction;
