Agriculture Fence Mesh Welding Machine 50mm 300mm Welded Mesh Making Machine
Agriculture Fence Mesh Welding Machine 50mm 300mm Welded Mesh Making Machine
Agriculture Fence Mesh Welding Machine 50mm 300mm Welded Mesh Making Machine
Agriculture Fence Mesh Welding Machine 50mm 300mm Welded Mesh Making Machine
Agriculture Fence Mesh Welding Machine 50mm 300mm Welded Mesh Making Machine
Agriculture Fence Mesh Welding Machine 50mm 300mm Welded Mesh Making Machine
Specifications
Brand Name :
DIAOZHUO
Model Number :
DZ1500 DZ1500 Z2000 DZ2500
Certification :
CE ISO9001
Place of Origin :
HEBEI, CHINA
MOQ :
1set
Payment Terms :
L/C, D/P, T/T
Supply Ability :
30 sets per month
Delivery Time :
20-30 days
Packaging Details :
nude
Price :
variable
product name :
fence mesh welding machine
material :
low carbon steel wire, black wire, galvanized wire
control :
PLC automatic
line wire feeding :
pre-cut
cross wire feeding :
pre-cut and falling auto
control screen :
touch screen
Description

CE high qulaity welded wire mesh fence machine 3 - 6 mm wire diameter

welding fence machine

Highway, railway and various function of protection. For construction which used for basis of high building, roof mesh, floor mesh. It is also widely used in agriculture and poultry mesh, farming mesh and so on.

1. This machine adopts synchronous control technique. The center-control and welding time are composed of PLC.
2. The input front-panel has two forms, touch screen and keyboard that makes the machine more intelligent and reasonable and it could press at one time, welding repeatedly.
3. The longitude wires and cross wire distance can be adjustable by inputing the data what you want. The greatest advantage is that you can adjust the distance weft wire at random on the same piece of wire mesh sheet.
4. The finished product fence panel is smooth; the error of opposite angle line is small.

5. the line including straightener & cutting machine, 2 sets

Model DZ-250A
Wire diameter 2.5-6mm
Longitude wire space 50-300mm
Cross wire space Min.25mm/12.7mm
Mesh width/height Max.2.5m
Mesh length Max.6m
Welding electrodes 48pcs
Welding speed 50-75 times/min
Welding transformers 125kva*6pcs
Need air compressor 0.3m^3
Need power supply Min.160kva
Overall Size 5.4*3.2*1.7m
Weight

4200kg

Agriculture Fence Mesh Welding Machine 50mm 300mm Welded Mesh Making Machine
