380V 3KW Razor Barbed Wire Machine 1100mm×1000mm×2000mm
380V 3KW Razor Barbed Wire Machine 1100mm×1000mm×2000mm
380V 3KW Razor Barbed Wire Machine 1100mm×1000mm×2000mm
380V 3KW Razor Barbed Wire Machine 1100mm×1000mm×2000mm
380V 3KW Razor Barbed Wire Machine 1100mm×1000mm×2000mm
380V 3KW Razor Barbed Wire Machine 1100mm×1000mm×2000mm
380V 3KW Razor Barbed Wire Machine 1100mm×1000mm×2000mm
380V 3KW Razor Barbed Wire Machine 1100mm×1000mm×2000mm
Specifications
Brand Name :
diaozhuo
Model Number :
dz-2
Place of Origin :
hebei,Chian
MOQ :
1 pcs
Price :
6000usd
Payment Terms :
L/C, T/T
Supply Ability :
1 pcs/30 days
Delivery Time :
30 days
Packaging Details :
container
Name :
razor barbed wire machine
overall dimension :
1200*1000*1900mm
Rated Voltage :
380V
Power :
3KW
Producing speed :
220m/h/tape
weight :
1200kg
Description
380V 3KW Razor Barbed Wire Machine 1200*1000*1900mm
Product Description

1. Consist of razor strip making machine and coil machine.
2. Save 20% raw materials and cost.

Technical parameter

Punching machine
Model Five strip/ Nine strip
Voltage 380V, 50Hz or client's required voltage
Power 2.2kw
Producing speed 220-280m/h
Thickness 0.5±0.05mm
Pressure 25ton/ 40ton
Weight 1500kg / 2200Kg
Dimension 1100mm×1000mm×2000mm
Coiling machine of
Voltage 380V, 50Hz,or client's required voltage
Power 1.5kw
Producing speed 80Kg/h
Wire diameter 2.5mm
Weight 300Kg
Dimension 1100mm×750mm×1200mm
Mould type
Mould type Barb Length Barb width Barb spacing
R1 12±1mm 13±1mm 26±1mm
R2 12±1mm 15±1mm 26±1mm
R3 18±1mm 15±1mm 33±1mm
R4 22±1mm 15±1mm 34±1mm
R5 28±1mm 15±1mm 34±1mm
R6 30±1mm 18±1mm 34±1mm
R7 60±1mm 32±1mm 96±1mm
R8 65±1mm 21±1mm 100±1mm

Our Services
1. Guarantee period: 36 months
2. Customized machine.
3. OEM support.
4. Fast delivery.
5. Moderate price.
6. Online service or 24-hour email service.
Our engineers are available to install and maintain machine overseas.
