6mm Automatic Wire Mesh Welding Machine 55times/min With Mesh Cutting Line
6mm Automatic Wire Mesh Welding Machine 55times/min With Mesh Cutting Line
Specifications
Brand Name :
DIAOZHUO
Model Number :
DZ1500 DZ1500 Z2000 DZ2500
Certification :
CE ISO9001
Place of Origin :
HEBEI, CHINA
MOQ :
1set
Price :
variable
Payment Terms :
L/C, D/P, T/T
Supply Ability :
30 sets per month
Delivery Time :
20-30 days
Packaging Details :
nude
material :
3-6mm iron wire, galvanized wire
control :
PLC automatic
line wire feeding :
from coils
cross wire feeding :
pre-cut and falling auto or from coils
product name :
welding fence machine in rolls
engineer :
available to service machinery overseas
Description

Automatic 3 - 6 mm welding wire mesh fence machine rolling and panel

Packaging :

1. The spare parts and control cabinet will be loaded in wooden box.

2. The main machine is nude packing or plastic packing.

3. Also can do as customer's request.

Delivery:

20-40 days after the receipt of your deposit.

after sales services:

1. If buyer need,we can send our technical staff to the buyers factory to install the machine and providing the training in 30 days after the machines arrived the destination port.

2. Maintenance period:One year for whole machine except vulnerable parts.

3. Number of technical persons :one technician per machine

4. Fees:the buyer have to pay the technical salary 100 USD per day,and the round-trip tiket,accommodation and other related fees.

5. During the maintenance period.if the parts are broken caused by the product problem.seller will offer the parts for free,if you need we assign the tachicians to your factory ,then you will pay some related fees.

Technical Parameters:

Model 120B-1 120B-2
Input power 380V 50 Hz 380V 50 Hz
Max. width 1200mm 1200mm
Line wire space 25—200mm 25—200mm
Cross wire space 25—200mm 25—200mm
Line wire diameter 1.8—3.0mm 1.8—3.0mm
Cross wire diameter 1.8—2.5mm 1.8—2.5mm
Rated capacity 60kva*2 60kva*2
Welding point No. 16 16
Motor power 2.2kw 2.2kw
Feed line wire Coils wire Coils wire
Feed cross wire Coil wire Coils wire & pre-cut wire
Cutting mesh Automatic & manual Automatic & manual
Welding speed 55times/min 55times/min
Weight 2500kg 2800kg
Dimension(l*W*H) 2500*1800*1400mm 2500*1800*1500mm
