Rebar Ribbed Steel Cold Rolling Mill Machine , 4 -12 Mm Wire Making Equipment
Rebar Ribbed Steel Cold Rolling Mill Machine , 4 -12 Mm Wire Making Equipment
Rebar Ribbed Steel Cold Rolling Mill Machine , 4 -12 Mm Wire Making Equipment
Rebar Ribbed Steel Cold Rolling Mill Machine , 4 -12 Mm Wire Making Equipment
Rebar Ribbed Steel Cold Rolling Mill Machine , 4 -12 Mm Wire Making Equipment
Rebar Ribbed Steel Cold Rolling Mill Machine , 4 -12 Mm Wire Making Equipment
Specifications
Brand Name :
DIAOZHUO
Model Number :
DZ-YL14 DZ-YL-11 DZ-YL-4
Certification :
CE ISO9001
Place of Origin :
HEBEI, CHINA
MOQ :
1set
Payment Terms :
L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10sets per month
Delivery Time :
30-40days
Packaging Details :
with water-proof film covered or at customer's request
Price :
variable
product name :
cold roling twist wire making machine
engineer :
available to service machinery overseas
services :
3 years
wire diameter :
4 -12 mm
outlet wire :
4 -6 mm
speed :
max 150 m/min
Description

Cold Rolling Wire Drawing Screw Thread Line, Rebar Bar Ribbed Steel Cold Rolling Machine


(1) Introduction of Rebar/Bar Ribbed Steel Cold Rolling Machine
1 Derusting Machine
The machine is close type, there have three rotary wheels inside, we could adjust it up and down, it is easier for the raw materials installation, we could put the wire rod inside, then adjust the wheels.
2. Rolling mill
The rollers’ angle should be 120°, at the same center, first rolling mill is mainly for reducing the diameter, second set of rolling mill is for making the rebar,
3. Plate Machine
The machine is with electromagnetic motor, it offer the power for the whole line, the motor speed could be adjusting, it will change the rolling speed.
4. Stress-Relieving Machine
This machine is mainly for reducing the machine hardness.
5. The Wire Drawing Machine matches the moment type motor, the mainly spare parts is the wire wheel
6. Straight Machine and Cutter

(2) Parameters of Rebar/Bar Ribbed Steel Cold Rolling Machine

Model15000T20000T30000T
Power37.5kw66kw80kw
Max input wire diameter13.5mm14mm14mm/16mm
Output wire diameter4-12mm4-13mm4-14mm
Speed75m/min120m/min150m/min
Ribbed machine type150180180
Recoiler weight1T1T1T or 2T
Weight4T6T7.5T
Working dimension16-2016-2016-20


packing:

One 20ft container/Set

Package: Stretch Film or Pallet

Main Farm Fence Wire Machinery: 1 Unit

Coil Holder: Several Units

Tool Cabinet: 1 Unit

Spare Parts: Several Units

Payment:30% TT for advance payment, 70% TT after the copy of B/L.

services:

1. Farm Fence Wire Machinery Warranty: One Year.

2. Enough spare parts of machines could be supplied.

3. All machines were tested and adjusted before delivery.

4. Engineers available to service machinery overseas: Worker-training, installation.etc.

5. 24 hours technical support by e-mail or calling service.

Rebar Ribbed Steel Cold Rolling Mill Machine , 4 -12 Mm Wire Making Equipment
