Steel Iron Aluminum Sheet Metal Perforating Machine With Hydraulic Overload Protecting Device
Steel Iron Aluminum Sheet Metal Perforating Machine With Hydraulic Overload Protecting Device
Steel Iron Aluminum Sheet Metal Perforating Machine With Hydraulic Overload Protecting Device
Steel Iron Aluminum Sheet Metal Perforating Machine With Hydraulic Overload Protecting Device
Steel Iron Aluminum Sheet Metal Perforating Machine With Hydraulic Overload Protecting Device
Steel Iron Aluminum Sheet Metal Perforating Machine With Hydraulic Overload Protecting Device
Specifications
Brand Name :
DIAOZHUO
Model Number :
DZ-CKW250 DZ-CKW2000 DZ-CKW1500
Certification :
CE ISO9001
Place of Origin :
HEBEI, CHINA
MOQ :
1set
Payment Terms :
L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10 sets per month
Delivery Time :
20-30 days
Packaging Details :
with water-proof film covered or at customer's request
Price :
variable
engineer :
available to service machinery overseas
speed :
220 mesh/min
material :
steel cast
the precision of hole-punching :
0.1mm
Description

Automatic perforating machine hebei steel iron aluminum sheet metal perforating machine


Specifications of Punching Press:


ModelDZ31G-80DZ31G-125DZ31G-160DZ31G-200
Nominal Force(KN)800125016002000
Nominal Stroke(MM)2333
Slide Stroke(MM)30303030
SPM(MIN)160-280160-240160-220150-200
Max Die Height(MM)360400400420
Die Height Adjustment(MM)50505050
Boster(F.B*L.R*T)(MM)550*980600*1180700*1380800*1550
Boster Opening(F.B*L.R)(MM)500*950550*1050600*1250650*1450
Between Columns(MM)1000120014001600
Motor Power(KW)1118.52230
Air Pressure(MM)0.50.50.50.5
Net Weight(KG)9000115001500019000


the advantage of our machines:

1. Welded steel plate framework with high intensity of machine body.

2. The middle crankshaft adopts special rolling bearing,and the precision roller bearing is adopted for front and rear side.

3. Combined pneumatic friction clutch and brake.

4. Equipped with hydraulic overload protecting device.

5. Eight-side precision needle roller guide rail.

6. Pitman screw locked up with oil pressure.

7. Electric shut height adjustment with digital display.

8. Equipped with lifting balance cylinder device.

9. Duplex valves imported from Japan.

10. Control by PLC with international brand.

11. Buttons,indicators,AC contactors,air circuit breakers and other controlling devices are imported from international brand.

12. Electronic cam device with intelligent top dead center stop function and several safety function.

Optional air cushion device,NC feeding machine,light curtain and inverter with international brand to fulfill stroke adjustment.
