Straight Line Wire Drawing Machine , Low Carbon Steel Wire Drawing Machine
Straight Line Wire Drawing Machine , Low Carbon Steel Wire Drawing Machine
Straight Line Wire Drawing Machine , Low Carbon Steel Wire Drawing Machine
Straight Line Wire Drawing Machine , Low Carbon Steel Wire Drawing Machine
Straight Line Wire Drawing Machine , Low Carbon Steel Wire Drawing Machine
Straight Line Wire Drawing Machine , Low Carbon Steel Wire Drawing Machine
Straight Line Wire Drawing Machine , Low Carbon Steel Wire Drawing Machine
Straight Line Wire Drawing Machine , Low Carbon Steel Wire Drawing Machine
Specifications
Brand Name :
DIAOZHUO
Model Number :
DZ-BSJ650 DZ-BSJ900 DZ-BSJ1100
Certification :
CE ISO9001
Place of Origin :
HEBEI, CHINA
MOQ :
1set
Payment Terms :
L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20 sets per month
Delivery Time :
20-30 days
Packaging Details :
with water-proof film covered or at customer's request
Price :
variable
engineers :
available to service machinery overseas
Total compressing rate :
80%
function :
drawing wire
material :
High, medium, low carbon
control :
Frequency conversion control
type :
continue, pully drum
Description

Automatic straight line steel wire drawing machine lowest price

We have dry, straight wire drawing machine in various model sizes and designs to produce different dimensions of wire. With the latest technology and high machine quality, the machine could run at high speed and high stability. We assemble the various machines to create a custom production line, which will provide you with high quality wire.

Specifications: (Model of DZ8/560)

ITEM Unit Data
Diameter of inlet wire mm 5.5
Diameter of outlet wire mm 2.0
Content of C %

Low carbon steel wire;

SAE 1006-1010
Number of drawing capstan 8
Diameter of drawing capstan mm 560
AC motor of the capstan KW 18.5
Take-up type Φ600mm coiler
AC motor of coiler KW 15
Average reduction % 20%
Max. line speed m/s 16
Real operation speed m/s 11-13, depends on the material
Capstan set up Tilted type
Cooling type Inner water cooling&Outer wind cooling
Tension roller Pneumatic roller control
PLC Siemens S7 series
AC driver ABB
Interface Siemens MP277
Transducer TE
Low voltage parts, button, indicator Schneider
Noise DB Less than 80DB
