Specifications
Brand Name :
Fengshi
Model Number :
FS550
Certification :
FCC / CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
1 piece
Price :
480-568 usd/piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Piece/Pieces per Month
Delivery Time :
15-20 work day
Packaging Details :
Gravity carton + export wooden frame
Product Item :
55' high brightness LCD panel
Screen Size :
55 inch
Display Area :
1209.6*680.4mm
Outline Dimenssion :
1238.0*716.9*27mm
Panel Type :
High brightness LCD with WLED
Configuration :
RGB Vertical Stripe
Resolution :
1920*1080pixel
brightness :
5000nits
Aspect Ratio :
16:9
Description

55 Inch 1920*1080pixel High temperature resistant 1500/5000nits

Sunlight Readable tft display screen panel

FS550 is a color active ma trix TFT LCD open cell using amorphoussilicon TFT's (Thin Film

Transistors) as an active switching devices. This opencell has a 54.60 inch diagonally measured

active area with FHD resolutions(1920 horizontal by 1080 vertical pixel array). Each pixel is

divided into REDGREEN, BLUE dots which are arranged in vertical stripe and this open cell can

display 16.7M colors. The TFT-LCD panel used for this open cell is adaptedfor a low reflection and

higher color type.

Features
◉ LVDS interface with 2 pixel / clock
◉ High-speed response
◉ Low color shift image quality
◉ 8-bit color depth, display 16.7M colors
◉ High luminance and contrast ratio, low reflection and wide viewing angle
◉ DE (Data Enable) only mode
◉ ADS technology is applied for high display quality
◉ RoHS compliant
◉ High TNI 105℃
Application
◉ Home Alone Multimedia TFT-LCD TV
◉ Display Terminals for Control System
◉ Ultra High Definition TV(FHD TV)
◉ AV application Products

55 Inch Outdoor Readable Lcd Screen 1920*1080 Pixel 1500 / 5000nits

55 Inch Outdoor Readable Lcd Screen 1920*1080 Pixel 1500 / 5000nits

Parameter

Model Item 55.0'' high brightness LCD panel
Model FS550
Dimensions Screen Size 55 inches
Display Area 1209.6*680.4mm
Outline Dimenssion 1238*716.9*27mm
LCD OC Panel Type High brightness LCD with WLED
Configuration RGBW Vertical Stripe
Resolution 3840*2160pixel
Brightness 2000nits
Aspect Ratio 16:9
Constrast Ratio 1100:1 (Typ.) (TM)
Response Time 9ms (Typ.)(G to G)
Viewing Angle 89/89/89/89 (Min.)(CR≥10)
Driver Elements a-Si TFT-LCD
Surface Treatment Antiglare (Haze 3%), Hard coating (2H)
Display Color 1.07B
Display Mode IPS, Normally Black, Transmissive
Interface Type V-by-One 8 lane , 51 pins , Connector
Power Input Voltage DC24V
Power 160W
Weight Weight 13.5kg
Lifetime Backlit Lifetime 50000hrs
Temperature Operating Temp. 0°- 50°C
Storage Temp. -20°- 60°C

FAQ

1.Q: Are you a manufacturer or trading company?

A: We are a professional manufacturer specialized in sunlight readable LCD panel/LCM since

2016 located in Shenzhen.

2. Q: How long is the warranty?

A: Our officially promised warranty time is 1 year or 18months(Non-artificial damages) from

the date of delivery.

3. Q: Do you provide ODM/OEM or customized service?

A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available based on your

requirements.

In order to support different customers, we are able to supply:

(1) High Brightness LCD Panel: LCD panel+led driver board+auto dimming sensor

(2) Open Frame LCD Displays:LCD Panel+PSU+AD board(optional interface, eg:HDMI, VGA,

DVI, USB...)+Touch optional.

(3) Window Facing Displays:LCD Panel+PSU+AD board (network board optional)+fan system

+temperature control board+housing.

(4) Full Outdoor Displays: customized. eg: touch function, IP55/IP65 etc.

4. Q: What brand of OC do you use?

A:Original LG/SAMSUNG/AUO/BOE etc. A or A+ grade OC, we can guarantee each sunlight

readable outdoor lcd display will pass through strict quality inspection.

5. Q:What certifications you have?

A:The CE-EMC Certificate of Conformity, ISO certification, FCC certification.

6.Q:What is the temperature when the screen surface goes black?

A: Normal grade goes black over 68℃; industrial grade goes black over 105 or 110℃.

7.Q: What is the MOQ?

A: Sunlight readable high brightness outdoor lcd display Sample testing is acceptable, the price

is negotiable for bulk order.

8.Q: When will you delivery?

A: High brightness LCD panel sample order shipped in 3days, bulk order shipped with 2 weeks.
