• Product Description

The FX 2-10*1600mm thick sheet slitting line is capable of slitting stainless steel coils with a thickness up to 10mm and a width of 1600mm. It can handle coils weighing up to 25 tons and run at a maximum line speed of 30 meters per minute.

The slitting accuracy is ±0.25mm, ensuring precise and consistent slit widths. The machine is equipped with a PLC control system for easy operation and monitoring.

This slitting line is well-suited for processing thick, heavy-duty stainless steel coils into narrower strips or sheets. It is commonly used in industries such as construction, manufacturing, and metal fabrication.

• Features and advantages

Material Capability:

Designed to slit stainless steel, which is known for its strength, corrosion resistance, and aesthetic appeal.

Can handle a maximum sheet thickness of 10mm, making it suitable for thick materials.

Width Capacity:

Capable of processing coils up to 1600mm in width, allowing for the slitting of wide sheet materials into narrower strips of varying widths based on requirements.

Coil Weight Capacity:

Built to handle heavy-duty coils, supporting a maximum coil weight of 25 tons. This ensures that large coils can be processed efficiently without frequent reloading, increasing productivity.

Line Speed:

Operates at a maximum speed of 30 meters per minute, which provides a balance between speed and precision, making it an efficient solution for high-volume production environments.

• Technical parameters

Note: The above is standard for reference. Customized slitting line as per customer's requirements and demands would be available.

• Process flow:

Entry coil car→Decoiler →Press and pinch device→Hydraulic cutter → Loop →Side guide device→ Double Slitter →Scrap winder→Loop →Tension stand →Recoielr→Exit coil car

Following figure is for reference only.

• Applications

The FX 2-10*1600mm thick sheet slitting line finds applications in various industries that require processing of thick materials, such as heavy-gauge steel coils or metal sheets.

This slitting line is ideal for industries that process stainless steel for a variety of applications, such as:

Automotive: For manufacturing components like body panels and structural parts.

Construction: For building materials like roofing, cladding, and framing.

Appliances: For producing metal parts in refrigerators, ovens, and other household appliances.

Metal Fabrication: For general metal processing and custom fabrication.

• Packaging & Shipping

Packaging:

All parts of the FX 2-10*1600mm thick sheet slitting line are fixed inside container by steel wires and special PET straps, in order to make sure all parts will not move during transportation and avoid any kinds of damage of machine and container.

Shipping:

Sea Freight: The FX 2-10*1600mm thick sheet slitting line is often shipped via ocean freight, especially for international transportation. The equipment is securely loaded into shipping containers or flat racks, which are then loaded onto cargo vessels. This mode is suitable for long-distance shipping and can accommodate larger and heavier slitting lines.

Air Freight: When there is a need for fast delivery or for shipping smaller or lighter slitting line, air freight can be used. The equipment is packed and loaded onto aircraft for transportation. Air freight is typically more expensive than ocean freight but offers quicker transit times.

• FAQ

1. What materials can this slitting line handle?

This slitting line is specifically designed for stainless steel sheets. It can handle other similar metals, but it is optimized for stainless steel processing.

2. What is the maximum thickness of the material that can be processed?

The slitting line can process materials up to 10mm in thickness.

3. What is the maximum coil width?

The line is capable of processing coils up to 1600mm in width.

4. Can this machine be customized?

Yes, the slitting line can be customized according to the specific needs of the customer, such as different coil diameters, strip widths, and additional automation features.

5. What is the delivery time after the order is placed?

Delivery time varies based on customization and production schedules, but typically it takes around 2-4 months from the time of order to delivery.
