• Product Description

The Φ760mm Coil I.D. Middle Thick Steel Coil Slitting Line For 1-6mm Stainless Steel Coils is designed to slit steel coils with a thickness range of 1-6mm and a coil width range of 600-1600mm. It can handle a variety of steel materials including hot-rolled/cold-rolled carbon steel, colored steel, and galvanized steel.

The FX-(1-6)*2000mm middle thick steel coil slitting line uses high-quality 6CrW2Si steel cutters with a hardness of HRC 56-58° to ensure precise and clean slitting of the stainless steel coils.

Overall, this steel coil slitting line is a robust and versatile solution for processing 1-6mm thick stainless steel coils into narrower widths, making it suitable for downstream applications such as cold rolling mills, welded pipe mills, and roll forming machines.

• Features and advantages

The thickness can range from the thinnest down to 1.0 mm, to the thickest up to 6.0mm

Strip Width, from the narrowest 800 mm to the widest 2000 mm

Coils Weight, up to 35 tons

Line Speed, up to 110 m/min.

- High precision slitting with tight tolerances

- Multi-strip slitting capability

- Wide coil capacity, accommodating various industry requirements

- Easy and quick setup with efficient changeover

- Safety features such as emergency stop buttons, safety guards, and sensors to protect operators and prevent accidents during operation

- Customization and flexibility, allowing for versatile applications across different industries.

- High production output

- Good and reliable quality control

• Technical parameters

Note: The above parameters are for reference. Customized slitting line as per customer's requirements and demands would be available.

• Process flow:

Entry coil car→Decoiler →Press and pinch device→Hydraulic cutter → Loop 1→Side guide device→ Double Slitter →Scrap winder→Loop 2 →Tension stand →Recoielr→Exit coil car

Following figure is standard for reference only.

• Applications

The FX-(1-6)*2000mm middle thick steel coil slitting line, also known as a medium gauge slitting line, finds applications in various industries that require processing materials of medium thickness.

Here's a simple introduction to the applications of the FX-(1-6)*2000mm middle thick steel coil slitting line:

Construction Industry: roofing, cladding, and structural components.

Shipbuilding: ship hulls, bulkheads, decks, and other structural elements.

Heavy Equipment Manufacturing: cranes, earthmoving machinery, and industrial machinery.

Oil and Gas Industry: pipelines, storage tanks, and other infrastructure.

Structural Steel Fabrication: buildings, bridges, and other infrastructure projects.

• Packaging & Shipping

Packaging:

All parts of the FX-(1-6)*2000mm middle thick steel coil slitting line are fixed inside container by steel wires and special PET straps, in order to make sure all parts will not move during transportation and avoid any kinds of damage of machine and container.

Shipping:

Sea Freight: The FX-(1-6)*2000mm middle thick steel coil slitting line is often shipped via ocean freight, especially for international transportation. The equipment is securely loaded into shipping containers or flat racks, which are then loaded onto cargo vessels. This mode is suitable for long-distance shipping and can accommodate larger and heavier slitting lines.

Air Freight: When there is a need for fast delivery or for shipping smaller or lighter slitting line, air freight can be used. The equipment is packed and loaded onto aircraft for transportation. Air freight is typically more expensive than ocean freight but offers quicker transit times.

• FAQ

Q1: What steel thicknesses can FX-(1-6)*2000mm middle thick steel coil slitting line handle?

A: Typically 1mm to 6mm in thickness.

Q2: What are the common applications for slit steel from this line?

A: Automotive parts, appliances, HVAC, construction, and metal fabrication.

Q3: What are the main advantages of this slitting line?

A: The key advantages of this slitting line include its ability to handle a wide range of cold-rolled steel materials, precise cutting accuracy, high production speed, and automated control system.

Q4: How does the slitting process work?

A: Coil loading, edge trimming, precision slitting, tension control, and recoiling.

Q5: What's the typical slitting width range?

A: Adjustable from 800mm to 2000mm.

Q6: What steel materials can the line accommodate?

A: A variety of carbon, stainless, and alloy steel coils.
