• Product Description

The 600mm Width Thin Sheet Slitting Line For 0.2-1mm Thick Color Steel Coil is a specialized machine used in the metal processing industry to cut large steel coils into narrower strips of desired widths. It is designed to handle steel coils with a maximum width of 600mm and can perform slitting operations on three separate strips simultaneously.

• Features and advantages

The thickness can range from the thinnest down to 0.20 mm, to the thickest up to 1 mm

Strip Width, from the narrowest 400 mm to the widest 600 mm

Coils Weight, up to 8 tons

Line Speed, up to 50 m/min.

- High precision slitting with tight tolerances

- Multi-strip slitting capability

- Wide coil capacity, accommodating various industry requirements

- Easy and quick setup with efficient changeover

- Safety features such as emergency stop buttons, safety guards, and sensors to protect operators and prevent accidents during operation

- Customization and flexibility, allowing for versatile applications across different industries.

- High production output

- Good and reliable quality control

• Technical parameters

Note: Customized slitting line as per customer's requirements and demands would be available.

• Process flow:

Entry coil car→Decoiler →Press and pinch device→Hydraulic cutter → Loop →Side guide device→ Double Slitter (with change car)→Scrap winder→Loop →Tension stand (with S ROLLS)→Recoielr→Exit coil car

• Applications

The FX0.2-1mm * 600mm thin sheet slitting line finds its application in various industries that require precise and efficient processing of thin-gauge metal coils.

Automotive Industry: trim strips, brackets, reinforcements, and specialized parts

Electronics Industry: electronic components, including connectors, shielding materials, and stamped parts.

Construction Industry: roofing sheets, wall panels, and profiles.

Packaging Industry: packaging materials like aluminum foils, flexible packaging films, and paperboard laminates.

Appliances and Household Goods: household appliances and goods.

• Packaging & Shipping

Packaging:

All parts of the FX0.2-1mm * 600mm thin sheet slitting line are fixed inside container by steel wires and special PET straps, in order to make sure all parts will not move during transportation and avoid any kinds of damage of machine and container.

Shipping:

Sea Freight: The FX0.2-1mm * 600mm thin sheet slitting line is often shipped via ocean freight, especially for international transportation. The equipment is securely loaded into shipping containers or flat racks, which are then loaded onto cargo vessels. This mode is suitable for long-distance shipping and can accommodate larger and heavier slitting lines.

Air Freight: When there is a need for fast delivery or for shipping smaller or lighter slitting line, air freight can be used. The equipment is packed and loaded onto aircraft for transportation. Air freight is typically more expensive than ocean freight but offers quicker transit times.

• FAQ

Q1: What is a light gauge slitting line?

A light gauge slitting line is a machine used to cut thin-gauge metal coils into narrower strips.

Q2: What materials can be processed using a light gauge slitting line?

Light gauge slitting lines are designed to process materials such as stainless steel, aluminum, copper, and other non-ferrous metals in thin gauges.

Q3: What are the main components of a light gauge slitting line?

The main components of a light gauge slitting line include an uncoiler, slitter head with circular blades, recoiler, tension control systems, edge guiding mechanisms, and scrap disposal units.

Q4: What is the purpose of a light gauge slitting line?

The purpose of a light gauge slitting line is to slit and cut metal coils into narrower strips with high precision, tight tolerances, and excellent strip quality.

Q5: What industries utilize light gauge slitting lines?

Light gauge slitting lines find application in industries such as automotive, electronics, construction, packaging, appliances, and household goods.

Q6: What are the benefits of using a light gauge slitting line?

Some benefits of using a light gauge slitting line include material utilization, waste reduction, flexibility in production, and the ability to meet specific customer requirements.
