Organic Fertilizer/compound Fertilizer Granules Making Machine price

Rotary drum churning granulator is just like the combination of rotary drum granulator and newly designed stirring tooth pellet machine. Both the inner rotary shaft and main body can rotate. When the raw material enter granulator. The interaction between stirring tooth and main body will convert powdery material into small particles. With the moving, they will gradually become rounder and harder. It is one of patent product of us and it is newly designed and widely used for Manure, Sludge, Grain sludge,sugarhouse filter mud, Cereal Slug, Straw, Sawdust, agaricus bisporus plant and also for Compound fertilizer(Organic fertilizer with NPK fertilizer).

Drum granulator

The pelleting rate of drum granulator is 70%, the average pelleting strength is >10N, the product nutrition is uniform, the adaptability is strong, from the machine into the steam, can also add phosphoric acid or ammonia solution, slurry, etc., complete the compound fertilizer production process of chemical reaction in the barrel body; It can also be used to supplement moisture and humidify the compound fertilizer production process.

Technical advantages

1, drum granulator has high pelletizing strength, wear resistance, low energy consumption, long service life, easy operation and maintenance. 2, ball forming rate of 70%, a small amount of returned material, returned material particle size is small, can be re-granulation; 3, through the steam heating, improve the temperature of the material, so that the material into the ball water is low, improve the drying efficiency; 4, with rubber engineering plastic as lining, the raw material is not easy to stick tube, and play the role of anti-corrosion and heat preservation;

Working principle

Drum granulator by the main motor drive belt and pulley, through the reducer drive to the drive shaft, through the open gear mounted on the drive shaft and fixed on the body of the big gear ring teeth, face to face work. The material is added from the feed end through the inside of the cylinder. Through the effect of the special structure inside the cylinder, it is made into particles and then discharged through the discharge port. Due to the continuous entry of materials, continuous rotation of granulator, can achieve mass production.

FAQ

1. Are you a manufacturer factory?

A: Yes, we are the professional manufacturer of the fertilizer machines for 30 years.

2. Could you provide the installation, commssioning, training or other kinds service?

A: Yes, we could arrange professional engineers to install the machines ,train your workers and test run the complate production line until your workers handle the operation; in addition ,we can supply the fertilizer fomulars for free.

3.Do you have customers near your factory, then can we visit the running fertilizer machines line?

A:Yes, there are many clients near our factory, we could take you to check the running fertilizer machines line.

4.Do you have experience in exporting, installing and traing the NPK fertilizer machines line in Africa, Southeast Asia, Middle East, South Asia, central Asia, Central America?

A:Yes, we have rich experience. Our fertilizer machines had exported to Saudi Arabia, India, Indonesia, South Africa, Nigeria, Dominica, Kazakhstan, Spain, Vietnam and other countries.
