Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine
Specifications
Brand Name :
Huaqiang
Certification :
ISO
Place of Origin :
China
MOQ :
1 set
Price :
US$ 4500-8000 per set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 sets per month
Delivery Time :
10-15 working days
Packaging Details :
wooden box or in containers or according to customer's needs
Model Number :
DCS-25
Production name :
Fertilizer granules packing machine
Weight range :
25--50kg
Warranty period :
1 year
After-sale service :
Field installation,commissioning and training
Condition :
New
Power :
220v/380v/customized
Description

25-50 Kgs/Bag Granules Fertilizer Packing Machine

Introduction to fertilizer granules packing machine

Our fertilizer granules packing machine is an automatic and intelligent packager which is specially designed, manufactured and tailored to different irregular materials and granular materials’ needs. It can realize the quantitative package of the supplies in bulk, and has already widely used in the food processing factory, industrial production line, etc.

Specifications of granules fertilizer packing machine

Material Granule
Weighing Range(kg) 20-50kg
Weighing Speed(bag/h) ≥500
Dividing value(g) 20
Level of accuracy 0.2
Power Supply Three-phase four-wire: AC 380V 220V 50Hz (User self-sufficiency) 50Hz (User self-sufficiency)
Power Consumption 0.4～0.6Mpa 1m3/h
Gas Source It is recommended to select an air compressor with a displacement of 0.25 m3／minor more.
Gas Consumption 0.4～0.6Mpa 1m3/h
Working Environment -20℃～＋40℃
Sensor ILGC-200KG-BA (KeLi Electric)
Computer Control Instrument Intelligent computer controller YH-3D YH-D8
Pneumatic Components Yadeke, Taiwan
Dust Removal Reserve dust outlet
Manufacturing Materials Contact with the material is made of carbon steel, good fluidity, wear resistance, corrosion resistance, easy to clean.
Feeding Method Arc valve 3 feed feed
Installation size(mm) 3120*1580*1350
Installation Method The scale body is directly docked to the storage bin and does not need to be added as an auxiliary steel frame. Occupied floor space is small and easy to install.

Working principle of granules fertilizer dryer machine

1.First of all, when the conveyor transports the granular materials into the stock bin, through the weighing senor, weighing instrument and weighing transmitter, PLC will automatically control the packing machine to open the feed port until the weight reach the standard.

2.Then there needs a labor to put the bags under the unloading port.

3.After granular materials packed, the machine will automatically sew the fertilizer bags. In the end, the conveyor will deliver the packaging fertilizer to the finished products area.

Fertilizer Bagging Machine 50HZ Granules Or Powdery Fertilizer Packing Machine

Features of granules fertilizer packing machine

1. Using professional all-digital dual-core processing weighing instruments, the operation is simple and easy to understand, it can store a variety of ranges and other data.

2. The high, medium and low feeding methods guarantee high speed and high accuracy over a wide range of ranges.

3. It has powerful functions such as automatic calibration, tour correction data, out-of-tolerance alarm, and fault indication.

Advantages of granules fertilizer packing machine

1. Weighing control system is designed in accordance with the requirements of dust-proof and waterproof.

2. Speed adjustable: feeding methods of powder type of equipment is the pneumatic valves feeding or belt feeding. Feeding speed is controlled by controller and the speed can set at random.

3. Packager host applies LCD touch screen PLC control technology with reasonable structure

Application of granules fertilizer packing machine

1. Suitable for large amount of continuous quantities packaging for particle materials such as various fertilizers, seeds, rice, feedstuff, etc.

2. Suitable for high accuracy packaging of fertilizer processing factories, sugar-making plants, chemical industry as well as feedstuff industry.
