FFC FPC Flexible Flat Cable Connector H2.5mm Top Contact 12/16/20 Pin
FFC FPC Flexible Flat Cable Connector H2.5mm Top Contact 12/16/20 Pin
FFC FPC Flexible Flat Cable Connector H2.5mm Top Contact 12/16/20 Pin
FFC FPC Flexible Flat Cable Connector H2.5mm Top Contact 12/16/20 Pin
Specifications
Brand Name :
XTKCONN
Model Number :
FPC**-T2T1-0025-C
Certification :
CE,SGS,ROHS,ISO9001
Place of Origin :
Guangdong,China
MOQ :
500pcs
Price :
Negotiable price
Payment Terms :
L/C, T/T,Payyal
Supply Ability :
3KK pcs
Delivery Time :
5-7 days
Packaging Details :
vacuum package,boxes in carton
Pitch :
1.0mm
Height :
2.5mm
No. Of position :
4-40pin
Terminal/Contact :
Copper alloy
Housing :
LCP UL94V-0 Natural
Cover Material :
LCP UL94V-0 black
Description

FFC / FPC flat cable Connector 1.0mm Pitch Height 2.5 connector Top Contact 4/5/6/8/10/12/16/20Pin



Xietaikang’s FFC(Flexible Flat Cable) / FPC(Flexible Printed Circuit) connectors with wide variety of product line-up offer the best combination of signal reliability, compactness, wide circuit size range and cable style choices of any similar version in the market.

Super-fine pitch and small-size FFC/FPC Connectors with ZIF, slider, flip actuator and FPC-to-board styles and a variety of circuit sizes deliver both high reliability and speedy data rates.

Description

1.0mm pitch type connectors modified from 0.5mm pitch ones. (Only even-numbered pins are inserted.)Wide variations in stacking height and pin count are provided.For details, please refer to a 0.5mm-pitch type page of each Series


Specifications

Pitch 1.0mm
Height 2.5mm
No. Of position 4-40pin
Mounting Type SMT/ZIF
Contact Location Single-sided contact
Type Slide lock
Current Rating 0.5A/Pin Max
Voltage Rating 50V AC/DC MAX
Withstanding Voltage 250V AC,1min
Cover Material LCP UL94V-0 black
Housing LCP UL94V-0 Natural
Terminal/Contact Copper alloy
Plating Tin-plating / Gold-plating
Operation Temperature -25℃ to +85℃
Lead Time 7-10 working Days


FFC FPC Flexible Flat Cable Connector H2.5mm Top Contact 12/16/20 Pin

Our Services
Ruised offers one stop service for Modules and all kinds of electronic components.
Best Quality Assurance
1. We only provide the original new items, 100% make sure the best quality!
2. 60-days GUARRANTEE OF QUALITY (After Our Delivery Date).
Payment Methods :
We accept T/T, West Union, PayPal,Alibaba's online trade assurance,Escrow payment .
Refound or Replacement:
We accept return back itmes if the goods still remain in their original condition on the warrant time!
