Horizontal 0.5mm 45 Pin FPC Connector H2.0/3.0mm Flexible Printed Circuit Connector
Horizontal 0.5mm 45 Pin FPC Connector H2.0/3.0mm Flexible Printed Circuit Connector
Horizontal 0.5mm 45 Pin FPC Connector H2.0/3.0mm Flexible Printed Circuit Connector
Horizontal 0.5mm 45 Pin FPC Connector H2.0/3.0mm Flexible Printed Circuit Connector
Specifications
Brand Name :
XTKCONN
Model Number :
FPC**-T1T1-00**-C
Certification :
CE,SGS,ROHS,ISO9001
Place of Origin :
Guangdong,China
MOQ :
1000pcs
Price :
Negotiable price
Payment Terms :
L/C, T/T,Payyal
Supply Ability :
4KK pcs
Delivery Time :
5-7 days
Packaging Details :
vacuum package,boxes in carton
Pitch :
0.5mm
Height :
2.0mm ,3.0mm
Contact Location :
Single-sided contact
Current Rating :
0.5A/Pin Max
Voltage Rating :
50V AC/DC MAX
Pin :
4-60pin
Description

slider lock 0.5mm FFC FPC connector H=2.0 ,3.0 horizontal type

Description

This series is ZIF, SMT type FPC/FFC Connectors with slide locks which enable secure connection with flexible cables. These low profile connectors feature a total height of 2.0mm,with bottom contact or top contact.can provide 3.0mm height.

Specifications

Pitch 0.5mm
Height 2.0mm 4-60pin available
3.0mm 36-40-45-50-54-55-60pin available
Mounting Type SMT/ZIF
Contact Location Single-sided contact
Type Slide lock
Current Rating 0.5A/Pin Max
Voltage Rating 50V AC/DC MAX
Withstanding Voltage 250V AC,1min
Cover Material LCP UL94V-0 black
Housing LCP UL94V-0 Natural
Terminal/Contact Copper alloy
Plating Tin-plating / Gold-plating
Operation Temperature -40℃ to +85℃
Lead Time 7-10 working Days

Horizontal 0.5mm 45 Pin FPC Connector H2.0/3.0mm Flexible Printed Circuit Connector

Typical Applications

Tablet PCs / Notebook PCs,

DSCs / DVCs,

Audio Players,

FPD / LCD TVs,

Printers / Copiers,

Medical Equipment,etc.

FAQ

Q: Are you manufacturer ot trading company?
A: We are a manufacturer in Dongguan, China.
Q: When can we get the reply?
A: Any inquiries will be replied within 24 hours, but holidays are excepted.
Q: Can I get some samples?
A: Yes, sample order is available for quality check and market test.
Q: What’s the delivery time?
A: It usually takes about 7-15 working days to produce the products.
Q: What’s your payment term?
A: We usually accept T/T as the main payment term, and other payments can also be negotiated.
Q: Quality problems?
A: If there is any quality problem or question, we could offer technical support or return service.
