Specifications
Brand Name :
Yaning
Model Number :
YN-CAS01
Certification :
CE
Place of Origin :
China
MOQ :
1 unit
Price :
USD+1600-2100+unit
Payment Terms :
L/C, D/A, T/T, Western Union
Supply Ability :
3000+unit+per month
Delivery Time :
8-15days
Packaging Details :
The machine itself is first wrapped with plastic film, the four corners are protected by cardboard or protective foam, and then fixed in the pallet or wooden box.
Product name: :
Cargo Air Shower
Outside Dimension(L*W*H): :
2000*1000*2130mm
Internal Dimension(L*W*H): :
1500*880*1980mm
Material: :
Stainless steel, powder coated plate
Number of Nozzles: :
Customized
Efficiency: :
99.99%@0.3
Blowing Mode: :
left and right 2 sides
Noise: :
<65dB
Air shower time: :
0-99s Adjustable
Air Velocity :
22-27 m/s
Description

Product Details:

Intelligent Air Shower Tunnel Modular System For Clean Room / Goods Cargo

Product Parameter:

Product Parameter Power Supply: Three-phase,380V/50Hz
Product Name Cargo Air Shower Cargo Air Shower
Product Model YN-HLS-01 YN-HLS-02 YN-HLS-03 YN-HLS-04
Outside Dimensions WxDxH(mm) 2000x1000x2130 2000x1500x2130 2000x2000x2130 2000x3000x2130
Internal Size WxDxH(mm) 1500x880x1980 1500x1380x1980 1500x1880x1980 1500x2880x1980
Fan Power(W) 550Wx2pcs 750Wx2pcs 550Wx4pcs 550Wx6pcs
Nozzle 12 pcs 18 pcs 24 pcs 36 pcs
G4 Pre Filter Size(mm) 745x375x21x2pcs 900x375x21x2pcs 745x375x21x4pcs 745x375x21x6pcs
H13 HEPA Filter Size(mm) 610x610x69x2pcs 610x610x69x2pcs 610x610x69x4pcs 610x610x69x6pcs

Product Pictures detail:

Intelligent Air Shower Tunnel Modular System For Clean Room / Goods Cargo

Intelligent Air Shower Tunnel Modular System For Clean Room / Goods CargoIntelligent Air Shower Tunnel Modular System For Clean Room / Goods Cargo

Intelligent Air Shower Tunnel Modular System For Clean Room / Goods CargoIntelligent Air Shower Tunnel Modular System For Clean Room / Goods Cargo

Intelligent Air Shower Tunnel Modular System For Clean Room / Goods Cargo

Certificate:

Intelligent Air Shower Tunnel Modular System For Clean Room / Goods Cargo

Our Factory:

Intelligent Air Shower Tunnel Modular System For Clean Room / Goods Cargo

Dongguan Yaning Purificatication Equipment Co. Ltd was established in year 2011. It is located in Houjie town of Dongguan City. It is nearby Dongguan urban district with very convenient traffic access. It only takes one hour drive from our company to Shenzhen or Guangzhou airport. It is very convenient for overseas customers to visit us in a efficient way.
Our company occupy an area of 22,000 square meter with modernized office and workshop building. We are ISO 9001 certified and our major products has passed CE certification and obtained more than 20 patent. We are national certified high technology enterprise. Our Yaning brand purification equipment has won the honor "China Famous brand".

We have been concentrating on the research and design, production, sales and installation of purification equipment and after sales services since establishment. So far , we have grown up to be one of most powerful enterprise in purification industry in south China. Our main product cover several major categories and more than one hundred model type. Our main product include air shower room for person and cargo , clean room , pass box, clean bench, fan filter unit, HEPA filter box, laminar air flow ceiling etc. Our air filter product range from primary level to medium and high efficiency level in various types. We can also construct full set clean room project for customers as per specified technical requirement. Our equipment have been widely applied in hospital, health care, electronics, medicine, food, precise instruments, aerospace, automobile manufacturing industry and so on.
We have been positioning our market both at home and abroad since establishment. We have exported our purification equipment to more than 50 countries. They are distributed in North America , Euro, South America, Middle East, Asia. We have won very good reputation from overseas market and our business is growing fast.
We sincerely hope to establish long term business partnership with all friends at home and abroad. We will work with our partner shoulder by shoulder for a more prosperous future.
