60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves
60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves
60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves
60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves
Specifications
Brand Name :
JQ/OEM
Model Number :
Fiber Heat Shrink tube
Certification :
ISO 9001,ROHS CE-EMC FCC SDOC
Place of Origin :
Guangzhou,China
MOQ :
10000PSC
Payment Terms :
L/C, T/T, Western Union,Alipay
Supply Ability :
999999pcs per day
Delivery Time :
3-5 days,it depends on order quantity
Packaging Details :
cartoon box
Manufactuer :
Yes
Jacket :
PE PVC
Length :
60mm 40mm 50mm
Oem :
Available
Color :
white
Type :
heat shrink fiber splice protection sleeves
Package :
cartoon box
Use :
FTTX/FTTH
Description

60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves

Shrinkable sleeve is applied to the optical fiber closure to fix and protect the optical fiber when splicing.
The sleeve can be divided into two types(single and mass) according to the function. The single type is used for the single-fiber, and the mass type is used for the ribbon fiber. It is different in the reinforcement between two types. The single one realizes the reinforcement by the stainless steel needles, the later one via the ceramic reinforcement member to realize the function.Mass means there are several cores for the fiber. So the mass sleeve includes 4cores,6cores,8cores,12cores(for types).

60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves

Model Fiber optic heat shrinking sleeve/ tube
Type Single fiber, Ribbon fiber
Material Heat shrink tube, fusion tube, 304 steel rod
Length 40, 45, 50, 60mm
Steel rod diameter 1.5, 1.2, 1.0mm
Minimum fully recovery temperature 120 °C
Operating temperature -45 °C to + 100 °C
Standard Color Clear

Feature

60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves

Package

100pcs in one bag,10000pcs in one cartoon or according customer's requirments.

60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves

60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves

60mm Optical Fiber Heat Shrinkable Splice Protection Sleeves
