155BASE 60KM Single Fiber SFP Module Module LC Connector TX1550nm Wavelength
155BASE 60KM Single Fiber SFP Module Module LC Connector TX1550nm Wavelength
155BASE 60KM Single Fiber SFP Module Module LC Connector TX1550nm Wavelength
155BASE 60KM Single Fiber SFP Module Module LC Connector TX1550nm Wavelength
Specifications
Brand Name :
OE
Model Number :
SFP 155M 1550 D 60KM
Certification :
ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
5000PCS/month
Delivery Time :
5 work days
Packaging Details :
Carton
Fiber Type :
Dual
Connector :
LC
Optical :
DFB
Distance :
60KM
Wavelength :
TX 1550nm
Cable Type :
SMF
DDM :
With
Rate :
155Mbps
Description

155BASE 60KM SFP Single Mode Fiber Module LC Connector TX1550nm

PRODUCT DESCRIPTION

This module is designed to be compliant with SFF-8472 SFP Multi-source Agreement (MSA)

60KM Duplex LC Single Mode 155Mb/S Optical Transceiver Module Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA), The transceiver consists of four sections: the LD driver, the limiting amplifier, the 1550nm DFB laser and the PIN photo-detector. The module data link up to 60KM in 9/125um single mode fiber.

The transmitter section uses a multiple quantum well laser and is a class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.

PRODUCT FEATURES

Compliant with MSA SFP Specification

Distance up to 60KM

Hot Pluggable,Metal enclosure, for Lower EMI

DDM function optional

Digital Diagnostic Monitor Function Compatible with SFF-8472

Single 3. 3V Power supply

Operating data rate up to 155Mbps

Tx1550, 1550nm DFB Laser, PIN-TIA

Dual LC Connector Interface

Operating Case Temperature: Commerical:0 to 70 °C Industrial:-40 to 85 °C

2 years warranty

Applications:

-- Fast Ethernet
-- Metro/Access Networks
--100Base-LX Ethernet
--SONET OC-3/SDH STM-1

Specification of Receiver

Parameter Symbol Min. Typ. Max. Unit Note
Receiver Sensitivity PIN -34 dBm Note (1)
Los Of Signal Assert PA -40 dBm
Los Of Signal De-assert PD -36 dBm Note (2)
LOS Hysteresis PA-PD 0.5 2 6 dB
Receiver Overload Pmax -PIN -3 dBm

Note (1): Measured with Light source 1550nm, ER=8.2dB; BER =<10^-12 @PRBS=2^23-1 NRZ

Note (2): When LOS de-asserted, the RX data+/- output is High-level (fixed)

Specification of Transmitter

Parameter Symbol Min. Typ. Max. Unit Note
Average Output Power POUT -4 0 dBm Note (1)
Extinction Ratio ER 8.2 dB
Center Wavelength λC 1500 1550 1580 nm DFB Laser
Spectrum Bandwidth(-20dB) σ 1 nm
Differential Line Input Impedance RIN 90 100 110 Ohm
Output Eye Mask Compliant with G.959(class 1 laser safety) Note (2)

Note (1): Measure at 2^23-1 NRZ PRBS pattern

Note (2): Transmitter eye mask definition
