100GBASE-SR10 CFP Optical Module 850nm Multimode Fiber Transceiver 100m
100GBASE-SR10 CFP Optical Module 850nm Multimode Fiber Transceiver 100m
Specifications
Brand Name :
OE
Model Number :
CFP 100G 850 SR10
Certification :
ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
500PCS/month
Delivery Time :
5-8 work days
Packaging Details :
Carton
Wavelength :
850nm
Distance :
100M
Power Supply :
+3.3V
Rate :
100Gbps
DDM :
With
Form Factor :
CFP
Connector :
MPO/MTP
Cable Type :
MMF
Description

100GBASE-SR10 CFP Optical Module 850nm Multimode Fiber Transceiver 100m

Applications

Switches, Routers
Data Centers

PRODUCT FEATURES

Transmission data rate up to 11.2Gbit/s per channel
CFP MSA compliant
Hot pluggable electrical interface
Differential AC-coupled high speed data interface
10 channels 850nm VCSEL array
10 channels PIN photo detector array
Multi-mode ribbon cable of up to 100m
Management Interface and digital diagnostic monitoring through MDIO
With TX/RX monitors per lane
Power class 1 (<8W max)
Operating case temperature 0°C to +70°C
3.3V power supply voltage
RoHS 6 compliant

PRODUCT DESCRIPTION

The 100GBASE-SR10 CFP module supports link lengths of up to 100m and 150m, respectively, over laser-optimized OM3 and OM4 multimode fiber cables. It enables high-bandwidth 100 Gigabit Ethernet optical links over ribbon fiber cables terminated with female MPO/MTP 24-fiber connectors.

General

Device TypeCFP transceiver module
Enclosure TypePlug-in module
Approximate Width3.2 in
Approximate Depth5.7 in
Approximate Height0.6 in
Approximate Weight10.6 oz

Networking

Connectivity TechnologyWired
Cabling Type100GBase-SR10
Data Link Protocol100 Gigabit Ethernet
Data Transfer Rate100 Gbps
Optical Wave Length850 nm
Max Transfer Distance100m
FeaturesDigital Optical Monitoring (DOM) support
Compliant StandardsIEEE 802.3ba

Expansion / Connectivity

InterfacesDifferential AC-Coupled high speed data interface
Compatible Slots1 x CFP

Miscellaneous

Compliant StandardsLaser Class 1, FCC CFR21 Part 1040, IEC 60825-1, GR-326-CORE

100GBASE-SR10 CFP Optical Module 850nm Multimode Fiber Transceiver 100m
