SFP 10G 40km Compatible SFP Modules SM Simplex LC Connector Module
SFP 10G 40km Compatible SFP Modules SM Simplex LC Connector Module
SFP 10G 40km Compatible SFP Modules SM Simplex LC Connector Module
SFP 10G 40km Compatible SFP Modules SM Simplex LC Connector Module
Specifications
Brand Name :
OE
Model Number :
SFP 1.25G 1310 BD 40KM
Certification :
ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
5000PCS/month
Delivery Time :
5 work days
Packaging Details :
Carton
Fiber Type :
Simplex
DDM :
With
Power Supply :
+3.3V
Wavelength :
TX 1310nm , RX 1550nm
Form Factor :
SFP
Rate :
1.25G
Connector :
LC
Distance :
40KM
Description

40KM BIDI 1310/1550nm 1.25Gbps Compatible SFP Modules SM Simplex LC

PRODUCT FEATURES

Up to 1.25Gb/s Data Links

Hot-Pluggable

Single LC connector

Up to 40 km on 9/125μm SMF

1310nm FP laser transmitter

1550nm PIN-TIA

Single +3.3V Power Supply

Monitoring Interface Compliant with SFF-8472

Maximum Power <1W

Industrial / Commercial operating temperature range: -40°C to 85°C/0°C to 70°C Version available

2 years warranty

Applications

Fiber Channel

Switch to Switch interface

Switched backplane applications

Router/Server interface

Other optical transmission systems

PRODUCT DESCRIPTION

1.25Gbps SFP BIDI Optical Transceiver Module is small form factor pluggable module for bi-directional serial optical data communications such as STM-8, OC-24,Fiber Channel, It is SFP 20-pin connector to allow hot plug capability. This module is designed for single mode fiber and operates at a nominal wavelength of 1310nm.

SFP transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 40km transmission distance with SMF.The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Recommended Operating Conditions

Parameter Symbol Unit Min Typ Max
Storage Temperature Range Ts ℃ 0 70
Power Supply Voltage Vcc V 3.135 3.465
Data Rate Gb/s - 1.25 -

Specification of Transmitter

Parameter Symbol Min. Typ. Max. Unit Note
Average Output Power POUT -3 1 dBm Note (1)
Extinction Ratio ER 8.2 dB
Center Wavelength λC 1260 1310 1360 nm FP Laser
Spectrum Bandwidth(-20dB) σ 4 nm
Differential Line Input Impedance RIN 90 100 110 Ohm
Output Eye Mask Compliant with G.959(class 1 laser safety) Note (2)

Note (1): Measure at 2^23-1 NRZ PRBS pattern

Note (2): Transmitter eye mask definition

Specification of Receiver

Parameter Symbol Min. Typ. Max. Unit Note
Input Optical Wavelength λIN 1500 1550 1580 nm
Receiver Sensitivity PIN -24 dBm Note (1)
Los Of Signal Assert PA -35 dBm
Los Of Signal De-assert PD -28 dBm Note (2)
LOS Hysteresis PA-PD 0.5 2 6 dB
Receiver Overload Pmax -PIN -3 dBm

Note (1): Measured with Light source 1550nm, ER=8.2dB; BER =<10^-12 @PRBS=2^23-1 NRZ

Note (2): When LOS de-asserted, the RX data+/- output is High-level (fixed)
