100BASE 1490nm DFB Laser SFP Optical Module LC Connector RX1550nm BIDI 60KM

PRODUCT DESCRIPTION

SFP LC Connector 60KM Optical Transceiver Module Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The transceiver consists of five sections: the LD driver, the limiting amplifier, the digital diagnostic monitor, the DFB laser and the PIN photo-detector .The module data link up to 60KM in 9/125um single mode fiber.

SFP LC Connector 60KM Optical Transceiver Module is small form factor pluggable module for bi-directional serial optical data communications such as STM-8, OC-24,Fiber Channel, It is SFP 20-pin connector to allow hot plug capability. This module is designed for single mode fiber and operates at a nominal wavelength of 1550nm.

The SFP Module compliants with Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472. The fully SFP compliant form factor provides hot pluggability, easy optical port upgrades and low EMI emission.

PRODUCT FEATURES

Simplex LC Connector Interface

Hot Pluggable,Metal enclosure, for Lower EMI

Distance up to 60KM

Operating Case Temperature: Commerical:0 to 70 °C Industrial:-40 to 85 °C

Compliant with MSA SFP Specification

Digital Diagnostic Monitor Function Compatible with SFF-8472

Single 3. 3V Power supply

Operating data rate up to 155Mbps

Tx1490/Rx1550, 1490nm DFB Laser, 1550nm PIN-TIA

DDM function optional

2 years warranty

Recommended Operating Conditions

Specification of Transmitter

Note (1): Measure at 2^23-1 NRZ PRBS pattern

Note (2): Transmitter eye mask definition

Specification of Receiver

Note (1): Measured with Light source 1550nm, ER=8.2dB; BER =<10^-12 @PRBS=2^23-1 NRZ

Note (2): When LOS de-asserted, the RX data+/- output is High-level (fixed)

Applications

Fiber Channel

Switch to Switch interface

Switched backplane applications

Router/Server interface

Other optical transmission systems
