1490nm DFB Laser Fiber Optic SFP Module 100BASE 60KM Simplex LC RX1550nm
1490nm DFB Laser Fiber Optic SFP Module 100BASE 60KM Simplex LC RX1550nm
1490nm DFB Laser Fiber Optic SFP Module 100BASE 60KM Simplex LC RX1550nm
1490nm DFB Laser Fiber Optic SFP Module 100BASE 60KM Simplex LC RX1550nm
Specifications
Brand Name :
OE
Model Number :
SFP 155M 1490 BD 60KM
Certification :
ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
5000PCS/month
Delivery Time :
5 work days
Packaging Details :
Carton
Form Type :
SFP
Distance :
60KM
Wavelength :
TX 1490nm , RX 1550nm
DDM :
With
Connector :
LC
Cable Type :
SMF
Power Supply :
+3.3V
Rate :
155Mbps
Description

1490nm DFB Laser Fiber Optic SFP Module 100BASE 60KM Simplex LC RX1550nm

PRODUCT FEATURES

Single +3.3V Power Supply

Up to 155Mb/s Data Links

Hot-Pluggable

Up to 60 km on 9/125μm SMF

1490nm DFB laser transmitter

1550nm PIN-TIA

Single LC connector

Monitoring Interface Compliant with SFF-8472

Maximum Power <1W

Industrial / Commercial operating temperature range: -40°C to 85°C/0°C to 70°C Version available

2 years warranty

Product Applications

Storage device

Telecommunication

Fiber Channel

Switches

Routers

VPN equipment

Traffic control device

NIC network cards

Fiber Media Converter

Firewall

GAP

PRODUCT DESCRIPTION

The SFP Module compliants with Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472. The fully SFP compliant form factor provides hot pluggability, easy optical port upgrades and low EMI emission

155Mbps SFP BIDI Optical Transceiver Module Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA), The transceiver consists of four sections: the LD driver, the limiting amplifier, the 1550nm DFB laser and the PIN photo-detector. The module data link up to 60KM in 9/125um single mode fiber.

SFP LC Connector 60KM Optical Transceiver Module is small form factor pluggable module for bi-directional serial optical data communications such as STM-8, OC-24,Fiber Channel, It is SFP 20-pin connector to allow hot plug capability. This module is designed for single mode fiber and operates at a nominal wavelength of 1550nm.

1490nm DFB Laser Fiber Optic SFP Module 100BASE 60KM Simplex LC RX1550nm

SPEC

Parameter Symbol Min. Typical Max. Unit
Transmitter Section:
Center Wavelength λc 1490 1483 1490 1495 nm
Spectral Width σ 1 nm
Sidemode Supression ratio SSRmin 30 dB
Optical Output Power Pout -4 1 dBm
Extinction Ratio ER 9 dB
Optical Rise/Fall Time tr / tf 260 ps
Relative Intensity Noise RIN -120 dB/Hz
Total Jitter Contribution TX Δ TJ 0.284 UI
Receiver Section:
Optical Input Wavelength λc 1550 1530 1550 1570 nm
Receiver Overload Pol -3 dBm
RX Sensitivity Sen -34 dBm
RX_LOS Assert LOS A -40 dBm
RX_LOS De-assert LOS D -36 dBm
RX_LOS Hysteresis LOS H 0.5 dB
General Specifications:
Data Rate BR 155 Mbps
Bit Error Rate BER 10-12
Max. Supported Link Length on 9/125μm SMF@155Mb/s LMAX 60 km
Total System Budget LB 30 dB

Recommended Operating Conditions

Parameter Symbol Unit Min Typ Max
Storage Temperature Range Ts ℃ 0 70
Power Supply Voltage Vcc V 3.135 3.465
Data Rate Mb/s - 155 -
