100BASE LC SFP Module Single Mode 40KM TX 1310nm RX1550nm 155Mbps
100BASE LC SFP Module Single Mode 40KM TX 1310nm RX1550nm 155Mbps
100BASE LC SFP Module Single Mode 40KM TX 1310nm RX1550nm 155Mbps
100BASE LC SFP Module Single Mode 40KM TX 1310nm RX1550nm 155Mbps
Specifications
Brand Name :
OE
Model Number :
SFP 155M 1310 BD 40KM
Certification :
ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
5000PCS/month
Delivery Time :
5 work days
Packaging Details :
Carton
Connector :
LC
Rate :
155Mbps
Distance :
40KM
DDM :
With
Cable Type :
SMF
Fiber Type :
Simplex
Form Type :
SFP
Wavelength :
TX 1310nm , RX 1550nm
Description

Distance 40KM 1310nm Laser RX1550nm Fiber Optic SFP Module SM 100BASE LC

PRODUCT DESCRIPTION

The transmitter section uses a multiple quantum well laser and is a class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.

SFP transceivers are high performance, cost effective modules supporting dual data-rate of 155Mbps and 40km transmission distance with SMF.The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Applications

100Base Ethernet
Metro/Access Networks
1×Fibre Channel
Other Optical Links

PRODUCT FEATURES

Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
Data-rate of 155Mbps operation
1310nm FP laser and 1550nm PIN-TIA for 40km transmission
Compatible with SONET OC-24-LR-1
+3.3V single power supply
Operating case temperature:
Commercial : 0 to +70°C
Industrial : -40 to +85°C

Recommended Operating Conditions

ParameterSymbolUnitMinTypMax
Storage Temperature RangeTs℃0 70
Power Supply VoltageVccV3.135 3.465
Data Rate Mb/s-155-


100BASE LC SFP Module Single Mode 40KM TX 1310nm RX1550nm 155Mbps

SPEC

ParameterSymbolMin.TypicalMax.Unit
Transmitter Section:
Center Wavelengthλc 1310129013101330nm
Spectral Widthσ 4nm
Optical Output PowerPout-6 0dBm
Extinction RatioER9 dB
Optical Rise/Fall Timetr / tf 260ps
Relative Intensity NoiseRIN -120dB/Hz
Total Jitter ContributionTX Δ TJ 0.284UI
Receiver Section:
Optical Input Wavelengthλc 1550150015501580nm
Receiver OverloadPol-3 dBm
RX SensitivitySen -32dBm
RX_LOS AssertLOS A-40 dBm
RX_LOS De-assertLOS D -35dBm
RX_LOS HysteresisLOS H0.5 dB
General Specifications:
Data RateBR 155 Mbps
Bit Error RateBER 10-12
Max. Supported Link Length on 9/125μm SMF@155Mb/sLMAX 40 km
Total System BudgetLB26 dB
