Outdoor Fiber Optic Termination Box FTTH Access Network ROHS Certification
Outdoor Fiber Optic Termination Box FTTH Access Network ROHS Certification
Outdoor Fiber Optic Termination Box FTTH Access Network ROHS Certification
Outdoor Fiber Optic Termination Box FTTH Access Network ROHS Certification
Specifications
Brand Name :
OTOP / OEM Accepted
Model Number :
2 Port 86mm
Certification :
ROHS, ISO
Place of Origin :
China
MOQ :
1000pcs
Price :
Negotiable
Payment Terms :
D/A, T/T, L/C, D/A, D/P
Supply Ability :
1000000 pcs per month
Delivery Time :
5-8 working days
Packaging Details :
Carton
Material :
ABS PC
Color :
White
Port :
2
Adapter :
SC
Pigtail :
0.9mm
Size :
86 x 86mm
Description

FTTH Access Network Outdoor Fiber Optic Termination Box ROHS Certification


♦ Application
- Widely used in FTTH access network
- Telecommunication networks
- CATV networks
- Data communication networks
- Local area Networks


♦ Features
- Industry standard user interface, be made of high impact plastic
- Anti-UV, ultra violet resistant and rainfall resistant
- Can accommodate 2 SC/SX adapter or 2 LC/DX adapter
- Up to 2 FTTH drops
- Wall and pole mountable
- 2 inlet ports, 2 outlet ports


♦ Specifications

Model TypeType Size(mm)N.W(kg/pc)Material
1, 2 port86*86*230.12ABS





♦ Packing

Plastic bag and carton

Features

Low Insertion Loss
High Isolation
Low PDL
Compact Design
Wide Operating Wavelength: 1260nm~1620nm
Wide Operating Temperature: -5℃~75℃
High Reliability and Stability

Applications

CWDM System
PON Networks
CATV Links

Compliance

Telcordia GR-1209-CORE-2001

Telcordia GR-1221-CORE-1999

ITU-T G.694.1

RoHS


Features

(1) Industry Standard User Interface, be made of ABS plastic.
(2) Can accommodate 1x4,1x8,1X16, 2x4,2x8 & 2x16 PLC steel tube splitter. Rainfall resistant, outdoor using.
(3) Can load 24pcs LC, FC, ST, SC … adapters.
(4) Wall mounting and pole mounting application.
(5) 2pcs cable entry ports; cable can be entry without cutting.
(6) 24pcs exit ports for FTTH drop cable.

Application

(1) Widely used in FTTH access network.
(2) Telecommunication Networks
(3) CATV Networks
(4) Data communications Networks
(5) Local Area Networks
(6) Indoor and Outdoor Application.


FTTH Termination Box available for the distribution and terminal connection for various kinds of optical fiber system, Some are used for indoor cabling and others are designed to install on outdoor pole or wall mount use.They are of light and compact design, Mainly used in fiber optic drop cable, pigtails or splitters cablings in residential buildings area. Most of them are applied to wall mounted type. The capacity is optional, such as small single fiber distribution box, 2 ports, 4 ports, 6 ports, 8 ports, 12 ports, 16 ports, 24 ports or even high density fiber distribution requirements.

Small size and light weight for easy installation compact body.
Easy installations: Ready for wall mount – installation kits provided.
Lower layer for splicing .
Upper layer for cross-connecting and fiber distribution.
Fully stable adapter panel, no risk of movement.
Fiber can get in from bottom or side

Description
FTTH fiber optical terminal box, outdoor fiber optic termination box is used in wiring connection between optical cable and optical communication equipment, through adapter in distribution box, optical fiber jumper leads optical signal, realize optical wiring function, and can meet the optical splitter placed to achieve spectral function.

Features
ABS material used ensures the body strong and light.
Waterproof design for outdoor use.
Made of Grade A PC/ABS alloy material, working life more than 20 years.
Drop resistance, ability to work under vertical pressure of 500N.
Easy installations: Ready for wall mount installation kits provided.
Adapter slots used, no screws and tools needed for installing adapters.
Ready for splitters: designed space for adding splitters.
Double-layer design for easier installation and maintenances:
Lower layer for splitters and over length fiber storage.
Upper layer for splicing, cross-connecting and fiber distribution.
Cable fixing units provided for fixing the outdoor optical cable.
Accommodates both cable glands as well as tie-wraps
It is good for storage of fixing cable achieves.
It is applicable for (indoor and outdoor) (pole-mounted, wall-mounted).
The splicing part is convenient for protection and maintenance engineering.
Adapter baseboard and optical installation box baseboard uses a rotary design.
